I/O list
This display is used for monitoring purposes only!
5.5.1
Monitor input signals
Signal
Description/Messages
X00
Not assigned
X01
Current flows
X02
Emergency stop enabled
X03
Automatic start
X04
Foot-operated switch
X05
Not assigned
X06
Not assigned
X07
Not assigned
X10
Incremental transducer function
X11
Not assigned
X12
Not assigned
X13
Not assigned
099-010268-EW501
28.03.2011
Design and function
NOTE
Figure 5-17
I/O list
