Set Functional Sequence - EWM CB-007-1 Operating Instructions Manual

Design and function
Main menu
5.4.1.1

Set functional sequence

Item Symbol Description
1
T1
2
T2
3
T3
4
T4
5
T5
6
7
T10
8
T6
9
T7
10
T8
11
T9
12
13
14
16
6
1
2
3
4
5
16 15
0
T1
Tailstock delay
Changes to T1 affect T2
T2
Torch delay from
Starting T2 switches the welding machine on.
T3
Turn table rotation delay after the welding machine has been switched on.
T4
Wire feed unit delay after the welding machine has been switched on.
T5
Oscillator delay after the welding machine has been switched on.
Input field, program number
T10
Torch lift delay
T6
Turn table rotation stop delay after the welding machine has been switched off.
T7
Wire feed unit switch-off delay after the welding machine has been switched off.
T8
Oscillator switch-off delay after the welding machine has been switched off.
T9
Mini oscilloscope switch-off delay
Button, Index welding screen
Button, Settings screen
Button, Automatic screen
14 13
Figure 5-6
7
8
9
10
11
12
099-010268-EW501
28.03.2011
