Design and function
Main menu
5.4.1.2

Index welding

Item Symbol Description
1
2
3
4
5
6
7
8
9
10
11
12
13
18
0
Input field, welding angle
To enter the required welding angle for the sequence
Input field, rotational angle
To enter the required rotational angle for the sequence
Display field, Actual position
Button, Direction of rotation
Button, Functional sequence screen
Button, Settings screen
Button, Continue mode
Button, Automatic screen
Button, Manual screen
Button, Main menu
Button, Go to
The turn table moves to the position set in the "Degree" input field.
Input field, RPM
To enter the rotational speed
Input field, Repetitions
To enter the repetitions for the specified welding sequence
Figure 5-7
