8.5.8

Hardware Monitoring Submenu

Feature
CPU Temperature
Board Temperature
VCore
VMemory
+3.3Vin
+5Vin
VBAT
FAN Speed
8.5.9

Boot Screen Configuration Submenu

Feature
Splash Screen
Clear Splash Screen
Splash Screen Timeout
Summary Screen
Summary Screen Timeout 0 - 65535
Copyright © 2006 congatec AG
Options Description
no option Current processor die temperature.
no option Current board temperature.
no option Current Core voltage reading.
no option Current Memory voltage reading.
no option Current 3.3V reading.
no option Current 5V reading.
no option Current VBAT reading.
no option Current FAN speed.
Options Description
Disabled Disabled displays normal POST diagnostic messages.
Enabled Enabled displays OEM logo instead of POST messages.
Note: The default OEM logo is a dark screen.
Disabled Clear the splash screen after option ROM initialization.
Enabled
0 - 65535 Determines the time, the splash screen is displayed during option
ROM initialization.
Disabled Enable/Disable the summary screen during bootup.
Enabled
Determines the time, the summary screen is displayed before
booting any OS.
