Millimeter Wave Network Analyzer Configurations

Supported N5290/91A system components

N5290/91A supported PNA/PNA-X hardware:
PNA/PNA-X
N5222B
N5227B
N5242B
N5242B
N5247B
N5290/91A system supported millimeter wave test set controller configurations:
The N5290 and N5291A systems include either a 2-Port (Option 200) or a 4-Port (Option 400)
and includes the following interconnect kit options.
PNA/PNA-X Models
N5222B
Interconnect kit for 2-port test set
and 2-port VNA with 3.5 mm ports
2-Port PNA
N5227B
Interconnect kit for 2-port test set
and 2-port VNA with 2.4 mm ports
N5242B
4-Port PNA-X
N5247B
N5290/91A system supported millimeter wave frequency extenders:
PNA/PNA-X Frequency coverage
N5293AX03 900 Hz to 110 GHz
N5295AX03 900 Hz to 120 GHz
Цены и срок поставки уточняйте на сайте
Frequency coverage
900 Hz to 26.5 GHz
900 Hz to 67 GHz
900 Hz to 26.5 GHz
900 Hz to 26.5 GHz
900 Hz to 67 GHz
N5292A Test options/ Interconnect cable options
2-Port test set controller
(N5292A Option 200)
Option 222
Option 224
n/a
n/a
Bias tee configuration
Low frequency bias combiner with
built-in 50V 1A bias tee
Low frequency bias combiner with
built-in 50V 1A bias tee
www.2test.ru
Test set configuration
2-Port with Option 205
2-Port with Option 205
4-Port with Option 425
4-Port with Options 425, 029
4-port with Options 425,029
4-Port test set controller
(N5292A Option 400)
n/a
n/a
Option 442
Interconnect kit for 4-port test set
and 4-port VNA with 3.5 mm ports
Option 444
Interconnect kit for 4-port test set
and 4-port VNA with 2.4 mm ports
+ 7 495 215-57-17
, по телефону:
Cable length
1.2 m cable option
1.2 m cable option
info@2test.ru
или
