Configuring Oml And Vdi Banded Frequency Extenders With N5290/91A; Supported Software Application Options - Keysight Technologies N5290A Configuration Manual

13 | Keysight | Millimeter Wave Network Analyzers (N5290A/N5291A) - Cofiguration Guide
Configuring OML and VDI Banded Frequency Extenders with the N5290/91A
In addition to supporting the broadband frequency extenders from Keysight the N5292A test set controller may be configured to drive
Keysight supported frequency extenders from OML and VDI.
For a complete listing of supported frequency extenders available, please refer to the "Banded Millimeter Wave Network Analysis to
1.5 THz" technical overview literature number 5992-2177EN.
To interface the OML and VDI modules to the N5292A, add product number N5290A304 to the configuration of the N5290/91A.
This cable adapter includes a 1.2 m length cable with an interface to the N5292A and 3.5 mm (m) connectors for the RF, LO and IF
connection to the frequency extenders. For VDI /OML frequency extenders that require a longer length cable consider using the
N5261A/62A to control these modules.
Product description
All OML frequency extenders
VDI standard frequency extenders only
VDI mini frequency extenders

Supported Software Application Options

The following listed software options will operate over the full range of the pre-configured N5290/91A systems.
Software product Description
S93007A Automatic fixture removal
S93010A Time domain analysis
S93015A Dynamic uncertainty for S-parameter measurements
S93025A Basic pulsed-RF measurements
S93026A Advanced pulsed-RF measurements
S93029A Noise figure measurements
S93080A Frequency-offset measurements
S93082A Scalar mixer/converter measurements
S93084A Embedded-LO capability
S93086A Gain-compression measurements
S93088A Source phase control
S93089A Differential and I/Q device measurements
S930909A Spectrum analysis up to 90 GHz
S93093A Spectrum analysis to 120 GHz
S93094A Spectrum analysis beyond 120 GHz
S93460A True mode stimulus
S93118A Fast CW mode
1. Pulse requires hardware Options 021 and 022 on the PNA or PNA-X
2. S93026 limited to wideband pulse when used as a N5290/91A system level
3. Noise figure is supported for down converters
4. Require 4-port configurations of the N5290/91A
Цены и срок поставки уточняйте на сайте
Adapter cable Power supply requirements
N5290A304 1. N5260AK91 includes OML DC power supply adapter and U1570B power supply
2. A N5260AK91 is required for each OML frequency extender
N5290A304 Add option VDI-175 DC power supply
N5290A304 Includes DC power supplies with mini frequency extenders
www.2test.ru
Start frequency support
900 Hz
Yes
Yes
n/a
n/a
n/a
n/a
Yes
Yes
n/a
Yes
n/a
n/a
n/a
n/a
n/a
Yes
Yes
+ 7 495 215-57-17
, по телефону:
N5290/91
10 MHz
Yes
Yes
Yes
Yes 1
Yes 2
3
Yes
Yes
Yes
Yes
Yes
Yes
4
Yes
Yes
Yes
Yes
Yes 4
Yes
