HDMI SWITCHER 2x1 PIGTAIL
Dear Customer
Thank you for purchasing this product. For optimum performance
and safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.

1.0 INTRODUCTION

This is a kind of high performance HDMI Switcher. It can easily switches
two sources to one display. It not only has the key-press-switching
function, but also has intelligent function. With one fixed HDMI cable
(pigtail) this converter not only reduces cost but also save time for
consumers.
This kind of HDMI Switcher routes high definition video (in multiple
resolutions up to 1080p) and digital audio from any one of the two
sources to display units. All inputs accommodate the connections of
the high definition video sources simultaneously, compatible well for
HD-DVD,SKY-STB, PS3, Xbox360 etc. The output sends the high
definition audio/video signals to a high definition display.
1.1 INTELLIGENT FUNCTION
1) Once the source device is turned on or plugged in (should stay
power-on mode), the switcher will automatically select this source.
2) Once the source device is turned off or plugged out, the switcher
will automatically select the next power-on source depending on the
sequence
Note:
1) When the source devices are on the stand-by mode, its power
supply should be turned off, otherwise this switcher can not meet
intelligent function.
2) When plugged in or out, this switcher is completely intelligent.
