3.0 PACKAGE CONTENTS

Before attempting to use this unit, please check the packaging and

make sure the following items are contained in the shipping carton:

• Main unit.

• User's Manual

4) Connect the HDMI input sources to the HDMI Switcher. (Input cables

are optional)

*Please refer to connection diagram section.

5) Connect the fixed HDMI cable (pigtail) to display.

6) Press the "select" button to select input sources.

Attention: Insert / Extract cable gently.

5.1 CONNECTION DIAGRAM

HD DVD

PS3

HDMI SWITCHER 2 x1 PIGTAIL

2x1 SWITCH

HD TV
