HDMI SWITCH 3X1 PIGTAIL 8K
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or using this product. Please keep this manual
for future reference.
INTRODUCTION
This is a high performance HDMI Switch. It can switch one of three sources to one display. Press
the switch button to select channel 1, channel 2 or channel 3. With a piece fixed HDMI cable this
converter not only reduces cost but also save time for customers.
FEATURES
This HDMI Switcher has many features that enable it to perform in a superior manner. Among
those features you will find:
• Supports 3 HDMI inputs and 1 HDMI output: it can switch one of three sources to one display
connected.
• Supports highest video resolution 8K@60Hz and downward compatible.
• Compatibile with HDMI V1.2 devices.
• Supports 24bit, 30bit and 36bit deep color.
• Supports uncompressed audio such as LPCM.
• Supports compressed audio such as DTS Digital, Dolby Digital, DTS-HD and Dolby True HD.
SPECIFICATIONS
Output Video
HDMI
24/50/60 fps
HDMI Resolution
480p/576/480/576p/720/1080/1080p/2160p/4320p
HDMI /HDCP version
HDMI1.2 / HDCP 2.3
Deep color
24bit, 30bit, 36bit
DTS HD/Dolby * - trueHD/LPCM7.1/DTS Dolby*-AC3/DSD HD
Audio sopported
(HBR)
Transmission rate
48 Gbps
Distance of the input
<2m AWG24 HDMI 2.1 standard cable
and output cable
Operating Temperature
-15°C to +55°C
Operating Humidity
5% to 90% RH (no condensation)
POWER REQUIREMENT
External Power Supply
No power needed
ACCESSORIES ADAPTER
User Manual
Note: Specifications are subject to change without notice.
Note: When the HDMI switch is working, ensure that source devices such as DVD and diplay
devices are properly connected.
PANEL DESCRIPTIONS
4
1
HDMI 1 input port
2
HDMI 2 input port
3
HDMI 3 input port
WWW.TECHLY.COM
6
5
1
2
3
4
HDMI Output port
5
Switch button
6
LED Indicator
HDMI SWITCH 3x1 PIGTAIL 8K
CONNECTION AND OPERATION
Notebook
Signal input 3
Signal input 2
PS4/5
Signal input 1
Desktop
1) Connect an HDMI source device (such as DVD player) to one of the input ports of the HDMI
switch.
2) Connect display device such as HDTV's input port to the output of the HDMI switch.
3) After all connections are done, you can watch HD videos on your HDTV.
PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and make sure the following
items are contained in the shipping carton:
• Main unit
• User's Manual
SAFETY PRECAUTIONS
INTENDED USE
We do not permit using the device in other ways like described in this user's
manual. Use the product only in dry interior rooms. Not attending to these
regulations and safety instruction might cause fatal accidents, injuries, and
damages to persons and property. The manufacturer/supplier assumes no liability for
damages caused by failure to comply with the intended use.
C A U T I O N
RISK OF ELECTRIC SHOCK
DO NOT OPEN
mains and other equipment if a problem should occur. Do not expose the product to water
or moisture.
CAUTION
• Your product is not a toy and is not meant for children, because it contains small parts which
can be swallowed and can injure when used inappropriately!
• Please install the system and devices attached to it in a way that persons cannot be injured,
or objects not be damaged for example by dropping or stumbling.
• Please remove the packing materials, because children may cut themselves on them while
playing. Furthermore, there is a risk of swallowing and inhalation of incidentals and insulating
material.
• Avoid places with high temperatures, or humidity, or places which might come into contact
with water. Do not install the product close to openings of air conditioners, or at places with
an excessive amount of dust or smoke.
• Do not install the product at places subject to vibration, or oscillation
• Do not modify and alter the product and any accessories! Do not use any damaged parts.
• Keep enough space around all devices for a good ventilation and free motion and to avoid
damages.
Maintenance: Clean only with a dry cloth. Do not use cleaning solvents or abrasives.
Warranty: No guarantee or liability can be accepted for any changes and modifications of the
product or damage caused due to incorrect use of this product.
In compliance with EU Directive WEEE this product is marked with this symbol.
It means that used electrical and electronic products should not be mixed with
general household waste. There is a separate collections system for these
products in compliance with WEEE directive, otherwise contaminative and
hazardous substances can pollute the environment.
With the CE sign, Techly
®
European standards and directives.
HDMI output
HDMI display devices such as TV and projector
To reduce risk of electric shock, this
product should ONLY be opened by an
authorized technician when service is
required. Disconnect the product from
ensures that the product is conformed to the basic
