HDMI 3X1 BIDIRECTIONAL SWITCH
Dear Customer
Thank you for purchasing this product. For optimum performance and safety, please read these
instructions carefully before connecting, operating or using this product. Please keep this manual for
future reference.
1.0

INTRODUCTION

This is a kind of high performance HDMI Bidirectional Switch. It can switch one of three sources to
one display or switch one source to one of three displays. Press the switch button to select channel
1, channel 2 or channel 3. With a piece fixed HDMI cable this converter not only reduces cost but also
save time for customers.
1.1 FEATURES
This HDMI Switcher has many features that enable it to perform in a superior manner. Among those
features you will find:
• HDMI bidirectional switch, it can switch one of three sources to one display or switch one source to
one of three displays.
• Supports highest video resolution 1080p.
• Supports 250MHz/2.5Gbps per channel (7.5Gbps all channels) bandwidth.
• Supports 12bit per channel (36bit all channels) deep color.
• HDCP pass-through.
• Supports uncompressed audio such as LPCM.
• Supports compressed audio such as DTS Digital, Dolby Digital (including DTS-HD and Dolby True
HD).
• Supports 3D all format, including 1080p@23.98/24Hz, 720p@59.94/60Hz, bandwidth up to 250MHz.
