Package Contents; Panel Descriptions; Connection And Operation - Techly IDATA HDMI-3BI User Manual

Resolutions(HDTV)
Interlaced(50&60Hz)
Progressive(50&60Hz)
Warranty
Limited Warranty
Environmental
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
Power Requirement
External Power Supply
Power consumption (Max)
Regulatory Approvals
Converter Unit
Accessories Adapter
User Manual
Note: Specifications are subject to change without notice.

3.0 PACKAGE CONTENTS

Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the shipping carton:
Main unit.
User's Manual

4.0 PANEL DESCRIPTIONS

5.0 CONNECTION AND OPERATION

1) Connect the HDMI input sources or HDMI displays to the HDMI switcher.
(Input cables are optional)
*Please refer to connection diagram section.
2) Connect the fixed HDMI cable (pigtail) to display or HDMI sources.
3) Press the "select" button to select input sources or HDMI displays.
HDMI Bidirectional Switch
480i,576i,1080i
480p,576p,720p,1080p
1 Year Parts and Labor
0 ℃ to +70℃
10% to 85 % RH (no condensation)
-10℃ to +80℃
5% to 90 % RH (no condensation)
No power needed
5W
FCC,CE,UL
２
