  • Page 1 ADA-11040 User manual ADA-11040 RS485/RS422 to RF converter Copyright © 2001-2019 CEL-MAR sp.j. io_ada-11040_v1.00_en...

  • Page 2: Table Of Contents

    ADA-11040 Contents 1. GENERAL INFORMATION..................................3 1.1. WARRANTED INFORMATION............................... 3 1.2. GENERAL CONDITIONS FOR SAFE USE............................ 3 1.3. CE LABEL....................................... 3 1.4. ENVIRONMENTAL PRESERVATION............................3 1.5. SERVICE AND MAINTENANCE..............................3 1.6. PACK CONTENTS..................................3 2. PRODUCT INFORMATION..................................3 2.1. PROPERTIES....................................3 2.2.

  • Page 3: General Information

    1.1. WARRANTED INFORMATION ADA-11040 converter is covered by a two year warranty from date of sale. In case of being damaged it will be repair or the damaged component will be replace. The warranty does not cover damage caused from improper use, materials consumption or any unauthorized changes.

  • Page 4: Description

    ADA-11040 converters work in the same radio channel, create wireless RF network. The device uses signals:RX+, RX-, TX+/A, TX-/B of RS485/RS422 for operation. To RS485 bus, constructed on the base of ADA-11040, can be connect 32 devices operating in half duplex mode to RS485(2W) bus and full duplex mode to RS485(4W) bus –...

  • Page 5: Isolation

    - not supply converter from power circuit device that generates large impulse interference such as transmitters, contactors. 3.1. ASSEMBLING The cover of ADA-11040 converter is adapted to assembly on TS-35 (DIN35) rail. To install the converter, should be mounted on the rail upper part of the cover then press bottom part to hear characteristic „Click” sound.

  • Page 6: Extensions Of Few Rs485/Rs422 Buses

    ADA-11040 3.2.2. EXTENSIONS OF FEW RS485/RS422 BUSES On the drawing below was shown, connection of two RS485 buses and MASTER device by the use of wireless RF network. ATTENTION ! THE CONFIGURATION OF RF PARAMETERS HAVE TO BE THE SAME FOR BOTH CONVERTERS, IN PURPOSE OF PROPER WORK WIRELESS CONNECTION.

  • Page 7: Computer Connection

    ADA-11040 3.3. COMPUTER CONNECTION To connect ADA-11040 to USB computer port, is needed additional converter USB to RS485 eg. ADAI9141, connected to RS485/422 port of ADA-11040 converter. Typical connections of ADA- 4040PC1 to PC are shown bellow. ADA-11040 ADA-I9141 RS485 SMA con.

  • Page 8: Rs485/Rs422 Network Connection

    ADA-11040 lets work on RS485 bus & RS422 bus. Both buses need correct cabling. 3.4.1. RS422 (4W) BUS CONNECTION Before connection 4-wire RS422 bus, should be setted MODE switch to RS422 mode, located on the front panel of ADA-11040. Then connect bus wires to connectors TX+/A, TX-/B, RX+, RX - as shown bellow.

  • Page 9: Rs485 (2W) Bus Connection

    2W, e.g. DR-15-24. Power cable from DC power supplies to device can not be longer than 3m. Should connect positive (+) end of DC power supplies to V+ device terminal and negative (-) end to V- on terminal block. ADA-11040 has protection against...

  • Page 10: Activation

    5.2.1. ADARF INSTALLATION The configuration of setting wireless RF network ADA-11040, can be made by the use of ADARF Software - selling with converter. The installation is automatically after insert the CD (compact disc) to an optical drive. If the autorun doesn't start, should run the file setup.exe located in main CD catalogue.
  • Page 11 ADA-11040 [3] open COM port, by button [Open COM]. [4] read configuration parameters of the converter by button [ Read Setting ] [5] read out configuration parameters are copied to edit boxes of section [RF Settings], by button [<<], [6] in the edit boxes, change RF configuration parameters,...

  • Page 12: Baud Rate Configuration Of Rs485/Rs422 Port

    ADA-11040 5.2.3. BAUD RATE CONFIGURATION OF RS485/RS422 PORT After read out the configuration parameters, change baud rate of RS485/422 serial port in section [UART Setting]: [8] select baud rate, [9] press button [Change] to send the parameter to the converter.

  • Page 13: Versions

    ADA-11040 7. VERSIONS ADA-11040 - Order example: Electronic versions: Product Symbol: ADA-11040-1-23 Basic 1 – basic version of electronic Galvanic isolation: 23 – galvanic isolation 1kV= (3-way), 1kV DC (3-WAY) - Standard 3kV DC (3-WAY) 8. SPECIFICATION TECHNICAL DATA Transmission Parameters...
  • Page 14 ADA-11040...
  • Page 15 ADA-11040...
  • Page 16 Thank you for purchasing CEL-MAR Company product. We hope that this user manual helped connect and start up the ADA-11040 Converter. We also wish to inform you that we are a manufacturer of the widest selections of data communications products in the world such as: data transmission converters with interface RS232, RS485, RS422, USB, Ethernet, Wi-Fi, Current Loop, Fibre-Optic Converters and the other.
