Figure 1-1. ATtiny817 Xplained Pro Evaluation Kit Overview
CURRENT MEASUREMENT
HEADER
USER LED0
MCU CURRENT
MEASUREMENT
SELECT JUMPER
I/O CURRENT
MEASUREMENT
SELECT JUMPER
QTOUCH BUTTONS
©
2017 Microchip Technology Inc.
ATtiny817 Xplained Pro
SW0 USER BUTTON
SW1 USER BUTTON
DEBUG USB
EXTENSION 3
HEADER
User Guide
POWER
HEADER
UPDI DEBUG
FOR EXTERNAL
DEBUGGER
ATTINY817
EXTENSION 1
HEADER
32kHz CRYSTAL
DS50002684A-page 5
