- Page 1 Side Speakers Accessory Spanish Product Description German Product Description Portuguese Product Description Italian Product Description Dutch Product Description French Product Description FLR100 Ergo In Demand, Inc. Contact Information: 4900 Industry Drive 800.888.6024 (Toll Free) Central Point, OR 97502 541.779.3763 (Office) 541.779.0829 (Fax)
- Page 2 A WARNING alerts you to the possibility of installer’s responsibility to make sure the combined weight of serious injury or death if you do not follow the instructions. all components located on the FLR100 does not exceed 20 lbs (9.1 kg) on each side. LEGEND...
- Page 3 Installation Instructions FLR100 DIMENSIONS Ergo In Demand, Inc. Contact Information: 4900 Industry Drive 800.888.6024 (Toll Free) Central Point, OR 97502 541.779.3763 (Office) 541.779.0829 (Fax) info@ergoindemand.com (Email)
-
Page 4: Tools Required For Installation
FLR100 Installation Instructions TOOLS REQUIRED FOR INSTALLATION 1/2" PARTS A (1) [Left Speaker Extension] B (1) [Right Speaker Extension] C (2) [Speaker E (4) Bracket] 1/4" D (4) F (4) 1/4-20 x 1/2" 1/4" G (2) [Knob] Ergo In Demand, Inc. Contact Information: 4900 Industry Drive 800.888.6024 (Toll Free) -
Page 5: Assembly And Installation
Tighten the side speaker bushings into the wall mount rails. (See Figure 3) NOTE: It may be necessary to lift slightly on the FLR100 in Figure 1 order to tighten the side speaker bushings. Install and tighten the knob (G) on each speaker extension. - Page 6 FLR100 Installation Instructions Attaching Speakers and Brackets Attach speakers (not included) to speaker brackets (C) following instructions included with speakers. Loosely attach one 1/4-20 x 1/2" hex head cap screw (D), one 1/4" lock washer (E) and one 1/4" flat washer (F) to top of each of the speaker brackets (C).
-
Page 7: Contact Information
FLR100 Installation Instructions USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378 Ergo In Demand, Inc. 800.582.6480 / 952.894.6280 4900 Industry Drive Central Point, OR 97502 877.894.6918 / 952.894.6918 Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands Contact Information: +31 (0)40 2668620 800.888.6024 (Toll Free)
