ELECTRICAL
Operating Voltage
Power Consumption
Back Up Battery
CONNECTORS, SIM ACCESS
Interface Connectors
Serial Interface
PHYSICAL
Dimensions
Weight
GPS
Location Technology
Location Accuracy
Tracking Sensitivity
Acquisition Sensitivity
AGPS Capable
MOUNTING
Molded mounting feet
CERTIFICATIONS
Pending certification FCC, CE, IC, PTCRB, GCF and Applicable Carriers
7-32 VDC (momentary)
9-30 VDC (start-up, operating)
3mA @ 12V (deep sleep)
20mA @ 12V (idle with IP connection)
70mA @ 12V
(active tracking GPS off cell enabled)
Lithium-Ion 5200mAh
(See online technical specifications for
latest details regarding battery options)
5-way power connector (5-pin)
18-way serial/1-wire connector (18-pin)
7-way I/O connector (7-pin)
(2) 2-wire RS-232 (TX/RX/Ground)
(1) 4-wire RS-232 (TX/RX/RTS/CTS/
Ground)
7.06" (L) x 6.93" (W) x 2.47" (H)
(179.43mm x 176.11 mm x 62.88 mm)
2.75lbs (44oz)
50 channel GPS (with SBAS, SABS:WAAS, EGNOS, MSAS,
GAGAN)
2.0 meter CEP (with SBAS)
-162dBm
-147dBm
