Connection To A Quake Satellite Modem; Power Up The Qtanium 400 - TELETRAC NAVMAN Qtanium 400 Installation Manual

8 Black
9 Brown/White
10 Brown
11 Yellow
12 Red
13 Orange/Black
14 Black/White
15 Red/White
16 Pink
17 N/A
18 N/A
4.8.7

Connection to a Quake Satellite Modem

If you want to connect the Qtanium 400 to a Quake Satellite Modem, you need the 18-Way
satellite modem cable. Satellite Modem for Qube 4 and Qtanium 400 Installation Manual.
Note When using the satellite modem, be aware that some of the I/O will be reserved
for satellite use.

Power Up the Qtanium 400

4.9
When the installation is complete, perform the following steps in the order listed to bring
the Qtanium 400 online promptly.
1. Screw the cellular (TNC) antenna cable to the connector on the Qtanium 400.
2. Screw the GPS (SMA) antenna cable to the connector on the Qtanium 400.
3. Insert fuses into fuse holders.
4. Remove and RETAIN the shipping plug from the 18-Way connector. If you have not
installed an 18-way cable, attach a blanking plug. (The shipping plug is used to Cold
Reset the Qtanium 400 in the unlikely event of any problems – see section 5.2.)
5. Test the installation as described in the following section.
Ground Ground Output
RxD-3 RS232 Serial Port 3/receive
TxD-3 RS232 Serial port
3/transmit
DO-1 Digital Output 1
~+12/24 V Power supply output
RTS-1 RS232 SP1/Request to
Send
TxD-1 RS232 Serial Port
1/transmit
RxD-1 RS232 Serial Port 1/receive
CTS-1 RS232 SP1/Clear to Send
Shipping Internal Battery disconnect
Shipping Internal Battery disconnect
19
Qtanium 400 | Installation Manual
