- Page 1 A WILSON ELECTRONICS BRAND Home Room Cell Signal Booster Installation Guide support.weboost.com 866.294.1660 NEED HELP?
- Page 2 ______ Index Package Contents Preparation Connect Inside Antenna To Booster STEP 1-A & B: Point Outside Antenna Toward Nearest Cell Tower STEP 2-A: Mount Bracket To Outside Antenna STEP 2-B: Route & Connect Cable To System STEP 3: Power Up The Booster & Optimize System STEP 4: Measuring Booster Performance Light Patterns...
- Page 3 ______ Package Contents Inside Outside Window Home 30' Cables Antenna Antenna Entry Cable Room Qty. 2 Power Roof/Pole Wall Mount Cable Supply Mount Bracket Connector Bracket HOME ROOM CELL PHONE SIGNAL BOOSTER...
- Page 4 2 people (a person to help with antenna calibration) Ladder Phillips-head screwdriver 10mm open-end wrench or adjustable wrench Drill (if routing cable through wall) 1.25”-2” diameter pole existing pole (or order #901117) Recommended: Power Strip with surge protection CELL PHONE SIGNAL BOOSTER HOME ROOM...
-
Page 5: Step 1-A & B: Connect Inside Antenna To Booster
______ Step 1-A & B: Connect Inside Antenna To Booster Connect Inside Antenna cable to the bottom port on Home Room booster labeled ‘INSIDE’ and place Inside Antenna in weak signal area at least 18 inches away from booster. NOTE: Do not connect booster to power until the system is fully installed. -
Page 6: Step 2-A: Point Outside Antenna Toward Nearest Cell Tower
NOTE: The Outside Antenna must be at least 20 feet horizontal or 50 feet vertical from the Inside Antenna for best performance. Make sure the Inside Antenna and Outside Antennas are setup so they are facing away from each other. CELL PHONE SIGNAL BOOSTER HOME ROOM... -
Page 7: Step 2-B: Mount Bracket To Outside Antenna
Bracket to attach the L-Bracket to a pole. Cell Tower Pole Mounting Option Pole (1.25”-2.0”dia.) L-Bracket Outside Antenna U-bolt & Pole Bracket NOTE: Mounting on existing roof exhaust pipe would be a good time-saver option. HOME ROOM CELL PHONE SIGNAL BOOSTER... - Page 8 ______ (STEP 2-B cont.) Wall Mounting Option Tap anchors in Drill holes using Fasten bracket to back 3/16 inch bit Secure bracket to wall of Outside Antenna mounting Outside Antenna on wall bracket sideview CELL PHONE SIGNAL BOOSTER HOME ROOM...
-
Page 9: Step 3: Route & Connect Cable To System
Antenna Booster Window Entry Cable RG-6 Cable RG-6 Cable A Window Entry Cable is provided to help make cable entry easier. Route cable to the Home Room booster and connect to top port labeled ‘OUTSIDE’. Outside Antenna Cell Tower Inside... - Page 10 Outside Antenna Booster Inside Antenna Window Entry Cable RG-6 Cable RG-6 Cable 50 FEET HORIZONTAL OR 20 FEET VERTICAL DISTANCE Outside Antenna Cell Tower Booster Inside Antenna Window Entry Cable Power Supply CELL PHONE SIGNAL BOOSTER HOME ROOM...
- Page 11 HOME ROOM CELL PHONE SIGNAL BOOSTER...
-
Page 12: Measuring Booster Performance
Test Mode’. Tip: Using the bar indicator on your cell phone can assist you in finding the strongest signal direction as well as placing calls in different locations. For changes/updates on this issue, periodically go to weboost.com/signalstrength. Android™ Settings > About Phone > Status or Network > Signal Strength or Network Type and Strength (exact options/wording depends on phone model). - Page 13 POOR DEAD ZONE SIGNAL STRENGTH 3G/1x -100 -101 -109 -110 DID YOU KNOW a signal increase of just 3dB is 2 4G/LTE -105 -106 -110 -111 -119 -120 times the power and signal amplification! HOME ROOM CELL PHONE SIGNAL BOOSTER...
-
Page 14: Light Patterns
Band has shutoff due to overload from nearby cell tower. Outside Antenna must be adjusted. Refer to Troubleshooting section. Light Off If the Signal Booster’s light is off, verify your power supply has power. CELL PHONE SIGNAL BOOSTER HOME ROOM... -
Page 15: Troubleshooting
Wall Mount Option: Change mount location. Move the Outside Antenna to a wall outside the building to see if the lights turn green. Un-plug and re-plug in power supply. HOME ROOM CELL PHONE SIGNAL BOOSTER... -
Page 16: Safety Guidelines
Inside Panel and Dome antennas and at least four feet of separation distance from desktop Antenna. Use only the power supply provided in this package. Use of a non-weBoost product may damage your equipment. -
Page 17: Antenna Kit Options
Wilson-400 Wall Mount Panel Antenna 311135-5820 RG-58 Wall Mount Panel Antenna 311155-0630 RG-6 Wall Mount Panel Antenna 311155-1150 RG-11 Wall Mount Panel Antenna 311155-40060 Wilson-400 Wall Mount Panel Antenna 311160 RG-58 RV Desktop Antenna HOME ROOM CELL PHONE SIGNAL BOOSTER... - Page 18 RG-58 Wide Band Directional 314453-5825 RG-58 Pole Mount Panel 314453-40075 Wilson-400 Pole Mount Panel 314473-0640 RG-6 Pole Mount Panel 314473-1175 RG-11 Pole Mount Panel 314475-0630 RG-6 Wide Band Directional 314475-1175 RG-11 Wide Band Directional CELL PHONE SIGNAL BOOSTER HOME ROOM...
-
Page 19: Specifications
This device complies with Part 15 of FCC rules. Operation is subject to two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment. - Page 20 2 YEAR WARRANTY weBoost Signal Boosters are warranted for two (2) years against defects in workmanship and/or materials. Warranty cases may be resolved by returning the product directly to the reseller with a dated proof of purchase. Signal Boosters may also be returned directly to the manufacturer at the consumer’s expense, with a dated proof of purchase and a Returned Material...
