4.

Control parameters and display channels

4.1 Overview of channels

Legend:
x
Corresponding channel is available.
x*
Corresponding channel is available when the corresponding
option is enabled
Please note:
Only if temperature sensors are connected, will S3 and S4
be displayed.
Arr
channel
1 2*
COL x x Temperature collector 1
TST x Temperature store 1
TSTL x Temperature store 1 base
TSTU x Temperature store 1 top
S3 x Temperature sensor 3
TRF Temperature return sensor
 
S4   Temperature sensor 4
h P x Operating hours relay 1
h P1 x Operating hours relay 1
h P2 x Operating hours relay 2
kWh Heat quantity kWh
 
MWh   Heat quantity MWh
time clock time
Arr 1-2 Arrangement
DT O x x Switch-on temperature difference
DT F x x Switch-off temperature difference
S MX x x Maximum temperature store 1
EM x x Emergency temperature collector 1
10
|
description page
11
11
11
11
11
11
11
11
11
11
12
12
11
12
12
13
13

Only if the option heat quantity measurement is activated
(OHQM), will the corresponding channel be available.

Only if the option heat quantity measurement is deactiva-
ted (OHQM), will the corresponding channel be available.
MEDT
Only if an antifreeze (MEDT) other than water or Tyfocor
LS / G-LS (MEDT 0 or 3) is used, will the channel anti-
freeze concentration (MED%) be displayed.
Arr
channel
1 2
OCX x x Option collector cooling collector 1
CMX x* x* Maximum temperature collector 1
OCN x x Option minimum limitation
collector 1
CMN x* x* Minimun temperature collector 1
OCF x x Option antifreeze collector 1
CFR x* x* Antifreeze temperature collector 1
OREC x x Option recooling
O TC x x Option tube collector
AH O x Switch-on temp. for thermostat 1
AH F x Switch-off temp. for thermostat 1
t1O x Switch-on time 1 thermostat
t1F x Switch-off time 1 thermostat
t2O x Switch-on time 2 thermostat
t2F x Switch-off time 2 thermostat
t3O x Switch-on time 3 thermostat
t3F x Switch-off time 3 thermostat
OHQM x Option heat quentity measurement
FMAX Maximum flowrate
 
MEDT   Antifreeze type
MED% MEDT MEDT Antifreeze concentration
HND1 x x Manual operation relay 1
HND2 x x Manual operation relay 2
LANG x x Language
PROG XX.XX Program number
VERS X.XX Version number
description page
13
13
13
13
14
14
14
14
15
15
15
15
15
15
15
15
12
12
12
12
15
15
15
