1.2.2. Protection Circuits

There are several protection circuits used in the amplifier. They are activated when one
or more parameters exceed defined values or some unwanted condition occurs.
VSWR too high
•
Anode current too high
•
Anode voltage error
•
Screen current too high
•
Screen voltage error
•
Grid current too high
•
Grid voltage error
•
Heating voltage error
•
Mistuning of PA
•
Temperature too high
•
Soft start for fuse protection
•
"switch-on blocking " at opened amplifier
•

1.2.3. Features

The manufacturer implemented some of the company's newest development results with
most wanted operating and safety features into this new model:
High level of protection
•
Memory for faults and warnings, easy maintenance
•
Automatic set-up anode current (BIAS) – no need to adjust manually after
•
changing the tube
Three programmable working modes of the centrifugal blower ( turbine ) + axial blower
•
Full QSK with silent relay
•
Many operational parameters to display
•
Easy transport due to detachable HV transformer
•
The smallest and lightest 4000 W Power Amplifier on the market
•
1.2.4. The Advantages of OM40001A
Full compatibility with: ICOM, ELECRAFT, KENWOOD, TEN-TEC ORION, YAESU, Icom
•
transceive protocol using by MicroHAM devices ( CI-V output ), FLEX Radios and
Anan.
RF sensitive Band and Frequency switching, for use with radios which do not
•
have
due to the much faster
• Automatic switching between bands. Automatic tuning within the band according to segments.
• Automatic switching of Band Pass Filter – BAND DATA output compatible with YAESU radios
(BCD code).
• Automatic switching of Antenna switches. The maximum number of antennas is 10, controlled
by BCD output code.
• Remote control via available PC Application.
PA_Manager_
CAT. We recommend using CAT and BAND DATA information
band changing whenever possible.
http://www.om-power.com/download/HF
