OM POWER OM4001A Manual page 25

Similar ways EBS2 can be preprogrammed (300mA by AUTO set).
Or another value of EBS2 by MANUAL Set.
protection circuit will stay active, max. allowed SWR is 3:1). If OFF is selected, higher SWR is
allowed, but reflected power is measured. If it exceeds 350W, transmit will be blocked.
Press EXIT.
You can try to do this manually, too.
Type of supported TCVR and working
Scroll to SET EBS1 MANUAL and
frequency are visible on the display.
press SET.
Use up/down buttons to set 20mA or
as close as possible value and press
AUTO LED is ON.
SAVE.
Scroll to CALIBRATION Ip, Is and
Type of supported TCVR and working
press SET. Calibration will be done
frequency are visible on the display.
automatically.
Scroll to SWR PROTECT and press
SET.
Type of supported TCVR and working
This feature allows user to switch
frequency are visible on the display.
OFF the SWR This feature allows
the user to switch OFF the SWR
protection.
We recommend to set it ON (SWR
AUTO LED is ON.
AUTO LED is ON.
