- Page 1 EEV-EX15 COM Express Type 10 Evaluation Carrier Board User’s Manual Ed – 24 December 2018 Part No. E2047EX1500R...
-
Page 2: Table Of Contents
2.3.17.1.3 PCI Express Signals ................26 2.3.17.1.4 Flat Panel LVDS Signals ............... 26 2.3.17.1.5 LPC Signals ................... 27 2.3.17.1.6 GPIO Signals ..................27 2.3.17.1.7 Power & System Management Signals ..........27 2.3.17.1.8 SATA Signals ..................27 2 EEV-EX15 User’s Manual... - Page 3 2.4.1 EEV-EX15 DB-A PCIe Expansion board ................. 29 2.4.2 EEV-EX15 DB-B LAN Expansion board .................. 29 EEV-EX15 Expansion Boards Jumper & Connector list ........30 2.5.1 EEV-EX15 DB-A PCIe Expansion board ................. 30 2.5.2 EEV-EX15 DB-B LAN Expansion board .................. 30 EEV-EX15 DB-A PCIe Expansion board Setting ..........
-
Page 4: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EEV-EX15 COM Express Type 10 Evaluation Carrier Board 1 x Expansion board for PCIe ... -
Page 5: Document Amendment History
User’s Manual 1.3 Document Amendment History Revision Date Comment December 2018 Avalue Initial Release EEV-EX15 User’s Manual 5... -
Page 6: System Specifications
USB3.0(contain 2 x USB2.0), 6 x USB2.0 1 x RJ45 HDMI DP/HDMI Connector, 1 x HDMI, 1 x DP Audio Jack 2 x Audio Jack Mechanical & Environmental Power Type Operating Temp. Standard: 0°C to 60°C (32°F ~ 140°F) 6 EEV-EX15 User’s Manual... - Page 7 (170mm x 170mm) than 410 x 360mm or smaller than 80 x 70mm) OS Support (listed in accordance with Intel According to COMe Module solution document) Note: Specifications are subject to change without notice. EEV-EX15 User’s Manual 7...
-
Page 8: Architecture Overview-Block Diagram
EEV-EX15 User’s Manual 1.5 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EEV-EX15. 8 EEV-EX15 User’s Manual... -
Page 9: Hardware Configuration
User’s Manual 2. Hardware Configuration EEV-EX15 User’s Manual 9... -
Page 10: Product Overview
EEV-EX15 User’s Manual 2.1 Product Overview 10 EEV-EX15 User’s Manual... -
Page 11: Jumper And Connector List
ATX1 Power connector 12 x 2 wafer, pitch 4.20mm ATX1 ATX2 ATX2 Power connector 2 x 2 wafer, pitch 4.20mm CPU fan connector 4 x 1 wafer, pitch 2.54mm FAN1 Display port connector /HDMI JDP_HDMI1 connector EEV-EX15 User’s Manual 11... - Page 12 5 x 1 wafer, pitch 2.00mm LCD Inverter connector JBKL1 Matching Connector: JST PHR-5 JLPC1 LPC port connector 7 x 2 header, pitch 2.00mm EDP connector 10 x 2 wafer, pitch 1.25mm EDP1 Battery connector 2 x 1 wafer, pitch 1.25mm 12 EEV-EX15 User’s Manual...
-
Page 13: Setting Jumpers & Connectors
BIOS ROM select Default ESPI/LPC select ESPI ERP setting ERP ON ERP OFF PSON Control Power button USB_HOST_PRSNT NO Detect DP/HDMI select HDMI (optional) LVDS/eDP select LVDS (optional) 2.3.2 Clear CMOS (JBAT1) Protect* Clear CMOS * Default EEV-EX15 User’s Manual 13... -
Page 14: Atx1 Power Connector (Atx1)
EEV-EX15 User’s Manual 2.3.3 ATX1 Power connector (ATX1) Signal PIN PIN Signal +3.3V +3.3V +3.3V PSON# PWR_OK +5VSB +12V +12V +3.3V 2.3.4 ATX2 Power connector (ATX2) Signal PIN PIN Signal +VIN +VIN 14 EEV-EX15 User’s Manual... -
Page 15: Cpu Fan Connector (Fan1)
User’s Manual 2.3.5 CPU Fan connector (FAN1) Signal +12V FAN_TACHIM 2.3.6 General Purpose I/O connector (JDIO1) Signal PIN PIN Signal DIO_OUT0_SD_CLK DIO_IN0_SD_DATA0 DIO_OUT1_SD_CMD DIO_IN1_SD_DATA1 DIO_OUT2_SD_WP DIO_IN2_SD_DATA2 DIO_OUT3_SD_CD# DIO_IN3_SD_DATA3 SMB_CLK SMB_DAT EEV-EX15 User’s Manual 15... -
Page 16: Tag Connector (Jtag1)
EEV-EX15 User’s Manual 2.3.7 TAG connector (JTAG1) Signal +3.3V GAL1_TCK GAL1_TDO GAL1_TDI GAL1_TMS I2C_DAT_UART_TX I2C_CLK_UART_RX GAL1_EN +3.3V 2.3.8 Front panel connector (JFP1) Signal PIN PIN Signal EXT_PWRBTN# SYS_RERST# SATA_LED_OUT# Signal Power Button Reset Power LED SATA LED 16 EEV-EX15 User’s Manual... -
Page 17: Lcd Backlight Brightness Adjustment (Jvr1)
BKLEN EDP_BRIGHT_CTRL 2.3.10.1 Signal Description – LCD Inverter connector (JBKL1) Signal Signal Description when LVDS_BKLT_CTRL is controlled by carrier board's JVR1, LVDS_BKLT_CTRL Vadj = 0.75V ~ 4.25V (Recommended: 4.7KΩ, >1/16W) BKLEN LCD backlight ON/OFF control signal EEV-EX15 User’s Manual 17... -
Page 18: Lpc Port Connector (Jlpc1)
EEV-EX15 User’s Manual 2.3.11 LPC port connector (JLPC1) Signal Signal LPC_AD0/ESPI_IO_0 +3.3V LPC_AD1/ESPI_IO_1 JLPC_RST# LPC_AD2/ESPI_IO_2 LPC_FRAME#/ESPI_CS0# LPC_AD3/ESPI_IO_3 PORT80_CLK LPC_SERIRQ/ESPI_CS1# +5VSB LPC_DRQ1#/ESPI_ALERT1 2.3.12 Battery connector (BH1) Signal +3.3VSB 18 EEV-EX15 User’s Manual... -
Page 19: Lvds Connector (Lvds1)
User’s Manual 2.3.13 LVDS connector (LVDS1) Signal Signal +3.3V +3.3V LVDS_DDC_SD LVDS_DDC_SC LVDSA_DATA0 LVDSA_DATA1 LVDSA_DATA0# LVDSA_DATA1# LVDSA_DATA2 LVDSA_DATA3 LVDSA_DATA2# LVDSA_DATA3# LVDSA_CLK LVDSA_CLK# +12V +12V EEV-EX15 User’s Manual 19... -
Page 20: Edp Connector (Edp1)
EDP_TX1# EDP_AUX# EDP_TX1 EDP_AUX EDP_TX2# EMB_HPD EDP_TX2 +VDD_EDP +VDD_EDP 2.3.15 Test position connector (JTP1) Signal PIN PIN Signal SER0_TX SER0_RX SER1_TX SER1_RX I2C_CK I2C_DAT TPM_PP +3.3VSB LID# SLEEP# GBE0_SDP USB0_HOST_PRSNT 15 SMB_ALERT# THRM# WAKE0# WAKE1# BATLOW# 20 EEV-EX15 User’s Manual... -
Page 21: Iet Connector (Iet_Cb1) Only Used In Production Testing
User’s Manual 2.3.16 IET connector (IET_CB1) only used in production testing Signal PIN PIN Signal SMB_CLK 33 SMB_DAT 35 WAKE1# CB_RST# ESPI_RESET# SLP_S3# IET_CLK LPC_AD0/ESPI_IO_0 LPC_AD1/ESPI_IO_1 LPC_AD2/ESPI_IO_2 LPC_AD3/ESPI_IO_3 52 LPC_DRQ0#/ESPI_ALERT0 LPC_SERIRQ/ESPI_CS1# LPC_FRAME#/ESPI_CS0# Signal Signal +12V +12V EEV-EX15 User’s Manual 21... -
Page 22: Com Express Connector (Com_Ex_Base1)
SATA1_RX- A21 B21 USB_SSRX0- A22 B22 USB_SSTX0- USB_SSRX0+ A23 B23 USB_SSTX0+ SUS_S5# A24 B24 PWR_OK USB_SSRX1- A25 B25 USB_SSTX1- USB_SSRX1+ USB_SSTX1+ A26 B26 BATLOW# A27 B27 (S)ATA_ACT# A28 B28 HDA_SYNC A29 B29 HDA_RST# HDA_SDI0 A30 B30 22 EEV-EX15 User’s Manual... - Page 23 GBE0_SDP A49 B49 SYS_RESET# LPC_SERIRQ A50 B50 CB_RESET# /ESPI_CS1# A51 B51 A52 B52 A53 B53 GPI0/SD_DATA0 A54 B54 GPO1/SD_CMD A55 B55 A56 B56 A57 B57 GPO2/SD_WP PCIE_TX3+ A58 B58 PCIE_RX3+ PCIE_TX3- A59 B59 PCIE_RX3- A60 B60 EEV-EX15 User’s Manual 23...
- Page 24 A82 B82 DDI0_PAIR3- /EDP_TX3- LVDS_I2C_CK LVDS_BKLT_CTRL/ A83 B83 /EDP_AUX+ EDP_BKLT_CTRL LVDS_I2C_DAT A84 B84 +ATX5VSB /EDP_AUX- GPI3/SD_DATA3 A85 B85 +ATX5VSB A86 B86 +ATX5VSB CB_EDP_HDP A87 B87 +ATX5VSB PCIE_CLK_REF+ A88 B88 BIOS_DIS1# PCIE_CLK_REF- A89 B89 DDI0_HPD A90 B90 24 EEV-EX15 User’s Manual...
- Page 25 TPM_PP USB7_HOST_PRSNT TYPE10# SER0_TX DDI0_CTRLCLK_AUX+ SER0_RX B99 DDI0_CTRLDATA_AUX- A100 B100 SER1_TX FAN_PWMOUT A101 B101 SER1_RX A102 B102 FAN_TACHIN LID# A103 B103 SLEEP# A104 B104 A105 B105 A106 B106 A107 B107 A108 B108 A109 B109 A110 B110 EEV-EX15 User’s Manual 25...
-
Page 26: Signal Description - Com Express Connector (Com_Ex_Base1)
PCI Express Differential Receive Pair 0-3 2.3.17.1.4 Flat Panel LVDS Signals Signal Signal Description LVDS_BKLT_CTRL Controls panel digital power. I2C clock output for LVDS display use. LVDS_I2C_CK LVDS_I2C_DAT I2C data line for LVDS display use. LVDS_VDD_EN LVDS panel power enables. 26 EEV-EX15 User’s Manual... -
Page 27: Lpc Signals
General purpose wake up signal. 2.3.17.1.8 SATA Signals Signal Signal Description SATA[0:1]_TX +/- Serial ATA Channel 0-1 transmit differential pair. SATA[0:1]_RX +/- Serial ATA Channel 0-1 receive differential pair. ATA_ACT# ATA (parallel and serial) activity indicator, active low. EEV-EX15 User’s Manual 27... -
Page 28: Usb Signals
DP AUX+function if DDI0_DDC_AUX_SEL is no connect DDI0_CTRLCLK_AUX+ HDMI/DVI 12C CTRLCLK if DDI0_DDC_AUX_SEL is pulled high DP AUX-function if DDI0_DDC_AUX_SEL is no connect DDI0_CTRLDATA_AUX- HDMI/DVI 12C CTRLDATA if DDI0_DDC_AUX_SEL is pulled high DDI0_HPD Digital Display Interface Hot-Plug Detect 28 EEV-EX15 User’s Manual... -
Page 29: Eev-Ex15 Expansion Boards
User’s Manual EEV-EX15 Expansion Boards 2.4.1 EEV-EX15 DB-A PCIe Expansion board 2.4.2 EEV-EX15 DB-B LAN Expansion board EEV-EX15 User’s Manual 29... -
Page 30: Eev-Ex15 Expansion Boards Jumper & Connector List
EEV-EX15 User’s Manual EEV-EX15 Expansion Boards Jumper & Connector list 2.5.1 EEV-EX15 DB-A PCIe Expansion board Jumpers Label Function Note AJPWR1/2 +12V VIN Power select 2 x 1 header, pitch 2.00mm Connectors Label Function Note PCIE connector (into the PCIE2) -
Page 31: Eev-Ex15 Db-A Pcie Expansion Board Setting
User’s Manual EEV-EX15 DB-A PCIe Expansion board Setting 2.6.1 +12V VIN Power select (AJPWR1/2) AJPWR2 AJPWR1 PCIEx4 Power* CN1(S4P) Power AJPWR2 AJPWR2 AJPWR1 AJPWR1 * Default 2.6.2 Power connector (ACN1) Signal +12V EEV-EX15 User’s Manual 31... -
Page 32: Gold Finger (Agf1)
B20 A20 B21 A21 PCIE_RXP_1_P4P1 B22 A22 PCIE_RXN_1_P4P1 PCIE_TXP_2_P4P1 B23 A23 PCIE_TXN_2_P4P1 B24 A24 B25 A25 PCIE_RXP_2_P4P1 B26 A26 PCIE_RXN_2_P4P1 PCIE_TXP_3_P4P1 B27 A27 PCIE_TXN_3_P4P1 B28 A28 B29 A29 PCIE_RXP_3_P4P1 PCIE_RXN_3_P4P1 B30 A30 B31 A31 B32 A32 32 EEV-EX15 User’s Manual... -
Page 33: Eev-Ex15 Db-B Lan Expansion Board Setting
User’s Manual EEV-EX15 DB-B LAN Expansion board Setting 2.7.1 Gold Finger (BGF1) Signal PIN PIN Signal SMB_CLK_P4L SMB_DAT_P4L +3.3V +3.3V +3.3V B10 A10 PCIE_WAKE#_P4L B11 A11 CB_RST#_P4L B12 A12 B13 A13 PCIE_CLK_REF_P4L PCIE_TXP_0_P4L B14 A14 PCIE_CLK_REF#_P4L PCIE_TXN_0_P4L B15 A15 B16 A16... -
Page 34: Mechanical Drawing
EEV-EX15 User’s Manual 3. Mechanical Drawing 34 EEV-EX15 User’s Manual... - Page 35 User’s Manual EEV-EX15 Unit: mm EEV-EX15 User’s Manual 35...
- Page 36 EEV-EX15 User’s Manual EEV-EX15 DB-A PCIe Expansion board EEV-EX15 DB-B LAN Expansion board Unit: mm Unit: mm 36 EEV-EX15 User’s Manual...
