  • Page 1 RIS 400-700 P EKO 3.0 MOUNTING AND INSTALLATION INSTRUCTION...

  • Page 2: Table Of Contents

    CONTENT 2. SYMBOLS AND MARKING 3. SAFETY INSTRUCTIONS AND PRECAUTIONS 4. DIMENSIONS AND WEIGHT 5. ELECTRICAL DATA 6. CONSTRUCTION 7. OPERATING CONDITIONS PACKAGE 9. TRANSPORTATION 10. UNPACKING 11. STANDART PACKAGE OF COMPONENTS 12. PLACE REQUIREMENTS 13. MOUNTING 13.1. INSTALLATION UNDER THE CEILING 14.

  • Page 3: Symbols And Marking

    2. SYMBOLS AND MARKING LN: XX000000 2019.01.01 Figure. 2.1. Technical label 1 - Logo; 2 - Product code (SKU); 3 - Product name; 4 - Technical data; 5 - Production place; 6 - Lot number and production date; 7 - Serial number.

  • Page 4: Dimensions And Weight

    In exceptional cases harmful gases could be drawn out of the chimney or extraction ducting back into the room. In this case we strictly recommend to turn off Salda Antifrost and use an external preheater for heat exchanger anti-frost protection (see Salda Antifrost function on the Remote controller manual).

  • Page 5: Construction

    Automatic control integrated Thermal efficiency Insulation of walls [mm] Cross-section of the power supply cabl [mm²] 3x1,5 3x1,5 3x2,5 3x1,5 Poles Circuit breaker* I [A] Fuse 5A RIS EKO 3.0 700PE 1.2 700PE 3.0 700PE 4.5 700PW - phase/voltage [50 Hz/VAC] ~1, 230 ~1, 230 ~3, 400...

  • Page 6: Operating Conditions

    7. OPERATING CONDITIONS +40 C +40 C +5 C +5 C +40 C +40 C +40 C +40 C +40 C +40 C -40 C -3 C +15 C -40 C -3 C +15 C Figure. 7.1. With external pre-heater operating conditions +40 C +40 C +5 C...

  • Page 7: Transportation

    9. TRANSPORTATION Figure. 9.1. Lifting with forklift. Only a product placed on a pallet may be lifted in order to prevent damage to the casing. 10. UNPACKING Accessories may be packed together with the product. Prior to transporting the unit, first unpack the accessories. •...

  • Page 8: Place Requirements

    12. PLACE REQUIREMENTS 1,5xL 1,5xL Min. distance to open the door - 1,5xL; Min. distance to open control box door - H > 400 mm. 13. MOUNTING The protective film is intended to protect the unit during transportation. It is recommended to remove the film because other- wise oxidation signs may occur.

  • Page 9: Connection Of The Air Duct

    14. CONNECTION OF THE AIR DUCT D2 dimensions depend on unit. 15. CONNECTION DIAGRAM * KE1 - used in electrical version. In horizontal version heater is positioned before supply fan; * KV1 - used in water version. For more informa- tion please, check the manual.

  • Page 10: Connection Of The Unit To Electric Network

    * Component/posibility to connect it depends on model. For more information please, check the manual 16. CONNECTION OF THE UNIT TO ELECTRIC NETWORK • Supply voltage to the unit must be connected by a qualified specialist following the manufacturer’s instructions and effective safety instructions. •...

  • Page 11: Fan

    18.2. FAN - Maintenance and repair should only be performed by experienced and trained staff. - The fan should be inspected and cleaned if needed at least 1/year. - Be sure the fan is disconnected from power source before performing any maintenance or repair. - Proceed to maintenance and repair after any rotation in the fan stopped.

  • Page 12: Electrical Heater

    18.4. ELECTRICAL HEATER Electrical heater does not need to be serviced additionally. It is compulsory to change filters as described above. Heaters have 2 thermal protections: automatically self-resetting, which activates at +50°C and the manually restored, which activates at +100°C. After the activation of the manually restored protection, the unit must be disconnected from the power supaply.

  • Page 13: System Protection

    air is used when ambient air temperature is less than the set temperature (see section II.6.3.3. of the FLEX description). This is so called “winter mode”. Cooling based on the extracted air is used when ambient air temperature is greater than the set temperature (see section II.6.3.3. of the FLEX description).

  • Page 14: Modbus Adresses

    Figure 19.2.2. Microswitches 1 and 2 19.3. MODBUS ADRESSES Data Quan- Name ModBus func. tity of Description Values dress data 1 - a c t i v e , Antifrost 01h_Read_Coils Plate heat exchanger frost protection function o-passive 1 - a c t i v e , Fire 01h_Read_Coils Fire alarm...

  • Page 15: Electrical Connection Of The Hvac Unit

    Texhaust 04h_Read_Input DTJ(100) temperature sensor value Hex: E0 Textract 04h_Read_Input Exhaust air temperature sensor value Hex: E0 ToutDoor 04h_Read_Input Ouside air temperature sensor value Hex: FFEC Twater 04h_Read_Input Return water temperature sensor value Hex: FFEC 19.4. ELECTRICAL CONNECTION OF THE HVAC UNIT Electrical connection can only be implemented by the qualified electrician in accordance with the applicable international and national electrical safety requirements and requirements for installation of electrical devices.

  • Page 16: System Adjustment Guidelines

    1_789.0046A.0.1.2-L-0k 19.5. SYSTEM ADJUSTMENT GUIDELINES 11 12 13 14 15 16 17 18 19 20 21 22 24 25 27 28 PE N L1 1 2 3 4 5 6 7 8 9 10 24 25 27 28 X16.5 X16.10 X16.7 X16.1 X16.2...

  • Page 17: Control Board Rg1

    20. CONTROL BOARD RG1 LED indications of the controller Pic. 3a LED2 Air damper close LED9 Medium fans speed LED2 + LED3 Air damper open LED10 Minimal fans speed LED4 Water valve open LED11 Supply air fan speed reducing LED5 Water valve close LED12 Preheater...

  • Page 18: Labeling, Characteristics Of The Controller And The System Components

    20.1. LABELING, CHARACTERISTICS OF THE CONTROLLER AND THE SYSTEM COMPONENTS Contact Labeling Description Max. load Min. load type [ A ] [ mA ] L(230V/50Hz power supply) N(230V/50Hz power supply) Electric heater Electric preheater/rotor ON/OFF 230V/50Hz Voltage of Normal speed for air fans Voltage of Min speed for air fans Extract room(s) air fan.

  • Page 19: Regular System Check-Up

    Supply air fan 0-10V pressure transmitter Fire guard Additional heate exchanger guard DI Filter guard Fans guard Extract air temperature sensor Temp. and humidity sensor for extract air. Extract air humidyti sensor Supply air temperature sensor Supply air temperature sen- sor.

  • Page 20: Electrical Connection Diagram

    21. ELECTRICAL CONNECTION DIAGRAM 21.1. RIS 400 PE 0,9 EKO 3.0 N L1 | EN RIS 400-700 P EKO 3.0 v2019.06...

  • Page 21: Ris 400Pe 1.6 Eko

    21.2. RIS 400PE 1.6 EKO 3.0 PE N L1 RIS 400-700 P EKO 3.0 v2019.06 EN |...

  • Page 22: Ris 400Pe 3.0 Eko

    21.3. RIS 400PE 3.0 EKO 3.0 N L1 | EN RIS 400-700 P EKO 3.0 v2019.06...

  • Page 23: Ris 400Pw Eko

    21.4. RIS 400PW EKO 3.0 PE N L1 RIS 400-700 P EKO 3.0 v2019.06 EN |...

  • Page 24: Ris 700 Pe R 1.2 Eko

    21.5. RIS 700 PE R 1.2 EKO 3.0 230V AC 230V AC 24VAC, 3-position Y1 - Control OPEN (AC 24 V) Y2 - Control CLOSE (AC 24 V) ON/OFF ON/OFF G - System potential AC 24 V Y1 Y2 1.737.0008A-0.1.1-L-2k X16.1 15 16 X16.5...

  • Page 25: Ris 700 Pe 3.0 R Eko

    21.6. RIS 700 PE 3.0 R EKO 3.0 230V AC 230V AC 24VAC, 3-position 1.736.0007A.0.1.0-L-2k Y1 - Control OPEN (AC 24 V) Y2 - Control CLOSE (AC 24 V) ON/OFF ON/OFF G - System potential AC 24 V Y1 Y2 X16.1 X16.5 15 16...

  • Page 26: Ris 700 Pe R 4.5 Eko

    21.7. RIS 700 PE R 4.5 EKO 3.0 230V AC 24VAC, 3-position 230V AC Y1 - Control OPEN (AC 24 V) Y2 - Control CLOSE (AC 24 V) ON/OFF ON/OFF G - System potential AC 24 V Y1 Y2 1.737.0008A-0.1.1-L-2k X16.1 X16.5 15 16...

  • Page 27: Ris 700 Pw R Eko

    21.8. RIS 700 PW R EKO 3.0 230V AC 230V AC 24VAC, 3-position Y1 - Control OPEN (AC 24 V) Y2 - Control CLOSE (AC 24 V) ON/OFF ON/OFF N L L G - System potential AC 24 V 1.738.0009A.0.1.0-L-1k X16.1 15 16 X16.5...

  • Page 28: Ris 700 Pe L Eko 3.0 1,2 Kw

    21.9. RIS 700 PE L EKO 3.0 1,2 KW | EN RIS 400-700 P EKO 3.0 v2019.06...
  • Page 29 RIS 400-700 P EKO 3.0 v2019.06 EN |...
  • Page 30 01-3-3 -RG2 01-2-3 01-2-3 01-2-3 13 14 01-3-2 DUTIES / NAME SIGNATURE DATE 0-10V 220.1103.0.1.0-PS SALDA UAB EI A. Šklenikas 2017-10-17 DRAWN BY W10\green Šild. el. 220.1103 EI D. Aleksandravičius 2017-10-17 CHECKED BY Principal connection scheme W10\yellow 2017-10-17 CHECKED BY...
  • Page 31 0-10V 0.75 Brown 0.75 Blue 0.75 Green-yellow 0-10V White -X52 White W7\white -X52 White W7\brown White -X37 0.75 Brown W8\white -X37 0.75 Blue W8\brown 0.75 Green-yellow -X33 794821-1 -X32 794821-1 221.1283.0.1.0-PS EI A. Šklenik DRAWN BY Pynė l. PR-221.1283 EI D. Aleksan CHECKED BY Pricipal connection scheme CHECKED BY...

  • Page 32: Ris 700 Pe L Eko 3.0 3.0 Kw

    21.10. RIS 700 PE L EKO 3.0 3.0 KW | EN RIS 400-700 P EKO 3.0 v2019.06...
  • Page 33 RIS 400-700 P EKO 3.0 v2019.06 EN |...
  • Page 34 01-3-3 -RG2 01-2-3 01-2-3 01-2-3 13 14 01-3-2 DUTIES / NAME SIGNATURE DATE 220.1102.0.1.0-PS EI A. Šklenikas SALDA UAB 2017-10-18 0-10V DRAWN BY Šild. el. 220.1102 W10\green EI D. Aleksandravičius 2017-10-18 CHECKED BY Principal connection scheme 2017-10-18 CHECKED BY W10\yellow...
  • Page 35 0-10V 0.75 Brown 0.75 Blue 0.75 Green-yellow 0-10V White -X52 White W7\white -X52 White W7\brown White -X37 0.75 Brown W8\white -X37 0.75 Blue W8\brown 0.75 Green-yellow -X33 794821-1 -X32 794821-1 221.1283.0.1.0-PS EI A. Škleni DRAWN BY Pynė l. PR-221.1283 EI D. Aleksa CHECKED BY Pricipal connection scheme CHECKED BY...

  • Page 36: Ris 700 Pe L Eko 3.0 4.5 Kw

    21.11. RIS 700 PE L EKO 3.0 4.5 KW | EN RIS 400-700 P EKO 3.0 v2019.06...
  • Page 37 RIS 400-700 P EKO 3.0 v2019.06 EN |...
  • Page 38 -RG3 01-2-3 01-2-3 01-2-3 13 14 01-3-2 DUTIES / NAME SIGNATURE DATE 220.1101.0.1.0-PS 0-10V EI A. Šklenikas SALDA U 2017-10-18 DRAWN BY W10\green Šild. el. 220.1101 EI D. Aleksandravičius 2017-10-18 CHECKED BY Principal connection scheme W10\yellow 2017-10-18 CHECKED BY W10\red...
  • Page 39 0-10V 0.75 Brown 0.75 Blue 0.75 Green-yellow 0-10V White -X52 White W7\white -X52 White W7\brown White -X37 0.75 Brown W8\white -X37 0.75 Blue W8\brown 0.75 Green-yellow -X33 794821-1 -X32 794821-1 221.1283.0.1.0-PS EI A. Škleni DRAWN BY Pynė l. PR-221.1283 EI D. Aleksa CHECKED BY Pricipal connection scheme CHECKED BY...

  • Page 40: Ris 700 Pw L Eko

    21.12. RIS 700 PW L EKO 3.0 | EN RIS 400-700 P EKO 3.0 v2019.06...
  • Page 41 RIS 400-700 P EKO 3.0 v2019.06 EN |...
  • Page 42 02-1-3 02-1-3 05-1-3 V2.5 V2.5 1-480706-0 -X16 -X16 Wire pin + termo tube -X32 794821-1 -X33 794821-1 0-10 VDC 24VDC Components and cables indicated in dotted line should be connected by the manufacturer or by the user. DUTIES / NAME 219.1133.0.1.2-PS EI A.
  • Page 43 0-10V 0.75 Brown 0.75 Blue 0.75 Green-yellow 0-10V White -X52 White W7\white -X52 White W7\brown White -X37 0.75 Brown W8\white -X37 0.75 Blue W8\brown 0.75 Green-yellow -X33 794821-1 -X32 794821-1 221.1284.0.1.0-PS EI A. Škleni DRAWN BY Pynė l. PR-221.1284 EI D. Aleksa CHECKED BY Pricipal connection scheme CHECKED BY...

  • Page 44: Ecodesign Data Table

    1994 1994 1994 ErP Compliance 2018 2018 2018 2018 Internet address for disassembly instructions www.salda lt RIS EKO 3.0 700 PE 1.2 700 PE 3.0 700 PE 4.5 700 PW Specific energy consumption (SEC) cold [ kWh/m a ] -74,4...
  • Page 45 AHS Warm [ kWh/a ] 1990 1990 1990 1990 ErP Compliance 2018 2018 2018 2018 Internet address for disassembly instructions www.salda lt RIS 400-700 P EKO 3.0 v2019.06 EN |...

  • Page 46: Declaration Of Confimity

    Should any alterations be made in the products, this declaration will no longer apply. Notified body: VšĮ Technikos priežiūros tarnyba, Naugarduko g. 41, LT – 03227 Vilnius, Lithuania, identification number 1399. Quality: Salda UAB activities are in line with the international quality management system standard ISO 9001:2015. Date...

  • Page 47: Warranty

    3.4. when the unit was used not for its original purpose. 3.5. Company SALDA UAB is not responsible for potential loss of property or personal injury in cases where AHU is manufactured without a control system and the control system will be installed by the client or third parties. The manufacturer’s warranty does not cover devices that will be damaged by installing the control system.
  • Page 48 Heat exchanger cleaning Every 3-4 Filter replacement months** Look at the product label. ** - At least. NOTE. The purchaser is required to fill in the “Product maintenance table”. MAN000114 MAN000114 Ragainės g. 100 +370 41 540 415 Šiauliai LT-78109, LITHUANIA office@salda.lt...
