  • Page 1 Avaya WLAN 8100 Configuration 1.1.0.0 NN47251-305, 01.01 August 2011...
  • Page 2 Product provided by Avaya including the selection, arrangement and While reasonable efforts have been made to ensure that the design of the content is owned either by Avaya or its licensors and is information in this document is complete and accurate at the time of protected by copyright and other intellectual property laws including the printing, Avaya assumes no liability for any errors.

  • Page 3: Table Of Contents

    Chapter 4: Configuring E911....................What is E911?............................29 Why is E911 important?..........................29 E911 configuration workflow........................30 Configuring the WLAN 8100 to send E911 traps..................31 Installing the Conveyant Sentry application....................32 Variable definitions........................... 33 Example 1............................34 Example 2............................36 Starting the Sentry service........................
  • Page 4 Avaya WLAN 8100 Configuration August 2011...

  • Page 5: Chapter 1: Configuring An Enterprise Wireless Lan Using Cli

    Configuring the BMDC on page 11 Configuring the peer controller on page 13 Configuration workflow The following workflow identifies the tasks in the order that you must complete them to successfully configure an Enterprise Wireless LAN. Avaya WLAN 8100 Configuration August 2011...
  • Page 6 Configuring an Enterprise Wireless LAN using CLI Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 7: Configuring The Amdc

    6. Enable routing using the following command: WC8180(config)#ip routing 7. Enable TELNET and SNMP access using the following command input: WC8180(config)#telnet-access enable WC8180(config)#snmp-server enable 8. Configure the wireless system interface with the following command input: WC8180(config)#wireless WC8180(config-wireless)#interface-ip 30.1.1.51 WC8180(config-wireless)#enable Avaya WLAN 8100 Configuration August 2011...

  • Page 8: Global Configuration

    Enter domain password: ********** Verify Domain password: ********** WC8180(config-wireless)# 10. Create and join the domain using the following command input: WC8180#wireless controller join-domain domain-name Avaya mdc-address 30.1.1.51 Enter Domain Secret: ***** Use 'show wireless controller domain-membership' to see join status.
  • Page 9 WC8180(config-security)#user-db membership flare UG-guest 7. Configure the CP network profile using the following command input: WC8180(config-wireless)#network-profile 4 Creating network-profile (id = 4) ... WC8180(config-network-profile)#profile-name NP-guest WC8180(config-network-profile)#ssid Guest WC8180(config-network-profile)#mobility-vlan MV-GUEST WC8180(config-network-profile)#captive-portal enable profile-id 1 WC8180(config-network-profile)#user-validation local Avaya WLAN 8100 Configuration August 2011...
  • Page 10 University Main bldg AP’s ------------------------- WC8180(config-wireless)#domain ap 00:24:B5:FD:54:00 Entering domain AP (mac = 00:24:B5:FD:54:00) configuration mode... WC8180(config-domain-ap)# WC8180(config-domain-ap)#profile-id 2 WC8180(config-wireless)#domain ap 00:24:B5:FD:64:40 Entering domain AP (mac = 00:24:B5:FD:54:00) configuration mode... Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 11: Configuring The Bmdc

    2. Associate ports to the configured VLAN using the following command input: WC8180(config)#vlan ports 1,2 tagging tagAll filter-untagged-frame enable WC8180(config)#vlan members add 20 1,2 WC8180(config)#vlan members add 30 1,2 WC8180(config)#vlan members add 128 1,2 WC8180(config)#vlan members add 129 1,2 Avaya WLAN 8100 Configuration August 2011...
  • Page 12 Enter domain password: ********** Verify Domain password: ********** WC8180(config-wireless)# 10. Join the domain using the following command input: WC8180#wireless controller join-domain domain-name Avaya mdc-address 30.1.1.51 Enter Domain Secret: ******* Use 'show wireless controller domain-membership' to see join status. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 13: Configuring The Peer Controller

    WC8180(config-if)#ip address 20.1.1.51 255.255.255.0 WC8180(config)#interface vlan 30 WC8180(config-if)#ip address 30.1.1.51 255.255.255.0 5. Associate the management VLAN using the following command input: WC8180(config)#vlan mgmt 20 WC8180(config)#ip route 0.0.0.0 0.0.0.0 30.1.1.1 1 WC8180(config)#ip route 0.0.0.0 0.0.0.0 30.1.1.1 enable Avaya WLAN 8100 Configuration August 2011...
  • Page 14 % 2 numbers and 2 special characters like !@#$%^&*() Enter domain password: ********** Verify Domain password: ********** WC8180(config-wireless)# 10. Join the domain using the following command input: WC8180#wireless controller join-domain domain-name Avaya mdc-address 30.1.1.51 Enter Domain Secret: ******* Use 'show wireless controller domain-membership' to see join status. Caution: Before proceeding, ensure “config sync”...

  • Page 15: Chapter 2: Configuring An Enterprise Wireless Lan Using Edm

    Configuring the BMDC on page 20 Configuring the peer controller on page 21 Configuration workflow The following workflow identifies the tasks in the order that you must complete them to successfully configure an Enterprise Wireless LAN. Avaya WLAN 8100 Configuration August 2011...
  • Page 16 Configuring an Enterprise Wireless LAN using EDM Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 17: Configuring The Amdc

    10. Navigate to Configuration > Wireless > Controller. Select MdcCapable, and set the Domain Password to elevate the interface to Mobility Controller Domain (MCD) capable. 11. Enter the DomainName and Secret to create and join the domain. Avaya WLAN 8100 Configuration August 2011...

  • Page 18: Global Configuration In Edm

    On the Insert Network Profile screen, enter the required information and click Insert to create the network profile. c. Select the Security tab. d. Select the network profile you want to edit. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...
  • Page 19 Radio 1 or 2 and enter a Vap ID and Network ID. 19. Navigate to Configuration > Wireless > Domain, and select the AP Table tab. 20. Click Insert. The Insert AP Table appears. Avaya WLAN 8100 Configuration August 2011...

  • Page 20: Configuring The Bmdc

    7. Navigate to Configuration > VLAN > VLANs. The VLAN screen appears on the right. 8. In the Routing column, select true from the drop down menu to enable routing on each VLAN. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 21: Configuring The Peer Controller

    5. To create the VLAN IP interfaces navigate to Configuration > VLAN >VLANs. a. Click the IP button on the Basic tab. The IP tab appears. b. Click Insert and enter the new IP and NetMask. c. Click Insert to save your changes. Avaya WLAN 8100 Configuration August 2011...
  • Page 22 Before proceeding, ensure “config sync” is executed on the AMDC to sync the global configuration across the domain.. 13. Map the MV to the local VLANs. AUTHOR: I was unable to figure out how to do this in EDM. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 23: Chapter 3: Configuring An Enterprise Wireless Lan Using Wms

    Enterprise Data Manager (EDM). For more information about configuring the domain controllers, see Configuring an Enterprise Wireless LAN using CLI on page 5 or Configuring an Enterprise Wireless LAN using EDM on page 15. Avaya WLAN 8100 Configuration August 2011...

  • Page 24: Importing Policies

    2. Right click on Mobility Domains in the WMS navigation tree. A sub-menu appears. 3. Select Import Polices. 4. Enter the Management IP address of the Mobility Domain. 5. Click Import Policies. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 25: Global Configuration

    5. Navigate to Mobility Domains > <Domain Name> > Policy > Network Profiles to configure the voice network profile: a. On the Network Profile tab, Click Add to add a new profile. b. Enter the profile name, Default Client VLAN (MV-VOICE), and User Validation. Avaya WLAN 8100 Configuration August 2011...
  • Page 26 Add the employee, voice, and guest network profiles to the Radio 1 and Radio 2 tables by double clicking each field and selecting them from to drop down menu. e. Click Add to create the profile. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...
  • Page 27 Select the controller then click Edit . Click on the LVID next to Mobility Vlan that needs to be modified and change the Local VLAN ID. 20. Navigate to Configuration> Mobility Domain-> Policy: Right Click on Policies and select Apply Policies. Avaya WLAN 8100 Configuration August 2011...
  • Page 28 Configuring an Enterprise Wireless LAN using WMS Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 29: Chapter 4: Configuring E911

    When any WLAN client device associates to a WLAN 8100 AP, an alert is sent to the Conveyant Scout application. When a client roams to another AP, an alert is also sent to the Conveyant Scout application.

  • Page 30: E911 Configuration Workflow

    APs still provide the correct ERL for a 911 call placed through it, even if they are moved. For more information on the E911 solution benefits, refer to WLAN 8100 E911 Solution Technical Configuration Guide (NN48500-610) E911 configuration workflow Configuring the E911 feature for WLAN consists of five high-level tasks.

  • Page 31: Configuring The Wlan 8100 To Send E911 Traps

    Configuring the WLAN 8100 to send E911 traps About this task Use the following procedure to configure the WLAN 8100 controller to send E911 traps. Note: You may need to configure your system's firewall to allow reception of SNMP traps. Some systems' firewall settings may block inbound SNMP traffic particularly if you are using a non- standard port for SNMP traps.

  • Page 32: Installing The Conveyant Sentry Application

    About this task Use the following procedure to install the Conveyant Sentry application on a Windows server. Procedure 1. Run the installer file “Sentry8100ScoutSetup.msi.” The installer Welcome screen appears. 2. Click Next. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...

  • Page 33: Variable Definitions

    The IP address of the CS1K call server. CS1K_Callserver_CommunityS This value should match the community string configured tring on the CS1K. SignalingServer_1_Community This value should match the community string configured String on the Signaling Server. Avaya WLAN 8100 Configuration August 2011...

  • Page 34: Example 1

    If the appender is not defined in the log4net assembly this type name must be fully assembly qualified.--> <appender name="LogFileAppender" type="log4net.Appender.RollingFileAppender" > <!--RollingFileAppender extends FileAppender to backup the log files when they reach certain size.--> <param name="File" value="8100Scout.log" /> <param name="AppendToFile" value="true" /> Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...
  • Page 35 <value></value> </setting> <setting name="MDCCapableCtrlr_1_CommunityString" serializeAs="String"> <value></value> </setting> <setting name="MDCCapableCtrlr_2_IPAddress" serializeAs="String"> <value /> </setting> <setting name="MDCCapableCtrlr_2_CommunityString" serializeAs="String"> <value /> </setting> <setting name="SentinelBaseUrl" serializeAs="String"> <value /> </setting> <setting name="SignalingServer_1_CommunityString" serializeAs="String"> <value></value> </setting> <setting name="SignalingServer_1_Username" serializeAs="String"> <value></value> Avaya WLAN 8100 Configuration August 2011...

  • Page 36: Example 2

    <value>00:00:15</value> ***Determines how often to update phone information in the CS1K Discovery Manager. Format is hh:mm:ss. Default is 15 seconds. </setting> <setting name="MDCCapableCtrlr_1_IPAddress" serializeAs="String"> <value>192.168.0.105</value> ***The IP address of your MDC capable controller. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...
  • Page 37 <setting name="SiteID" serializeAs="String"> <value>1</value> ***Do not edit this value. </setting> <setting name="SNMPTimeoutSeconds" serializeAs="String"> <value>30</value> ***Determines the Timeout in seconds for SNMP requests. </setting> <setting name="SNMPTrapPort" serializeAs="String"> <value>162</value> ***Determines the Port for receiving SNMP traps. </setting> </Conveyant.Sentry.Services.Properties.Settings> Avaya WLAN 8100 Configuration August 2011...

  • Page 38: Starting The Sentry Service

    Procedure 1. In Windows, click Start > Administrative Tools > Services. The Services screen appears. 2. Right-click on the Sentry8100Scout service. 3. Select Start from the right-click menu. The Sentry service starts. Avaya WLAN 8100 Configuration August 2011 Comments? infodev@avaya.com...
