- Page 1 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Release 7.0 NN47252-301 01.01 June 2014...
- Page 2 Documentation, Software, Hosted Service, or hardware provided by Avaya. All content on this site, the documentation, Hosted Service, and the Product provided by Avaya including the selection, arrangement and design of the content is owned either by Avaya or its licensors and is protected by copyright and other...
- Page 3 Avaya or such third party which may own the Mark. Nothing contained in this site, the Documentation, Hosted Service(s) and Product(s) should be construed as granting, by implication, estoppal, or otherwise, any license or right in and to the Marks without the express written permission of Avaya or the applicable third party.
-
Page 5: Quick Installation Guide
WAPs deliver robust wireless connectivity. This Guide covers the steps required to install the WAP on a ceiling or wall and connect and start the WAP. For detailed configuration information, refer to Using the Avaya OS for Avaya WLAN AP 9100 Series (NN47252-102). - Page 6 The WAP can be installed on the ceiling or on a wall or may be placed on a shelf. Choose a location that is central to your users. Refer to the Using the Avaya OS for Avaya WLAN AP 9100 Series (NN47252-102).
- Page 7 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Install the Locking Slug (Optional) If you are using a mounting kit and you wish to secure (lock) the WAP to its mounting plate after it is installed on the ceiling or wall, complete the following steps:...
- Page 8 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series 4A-Direct Ceiling or Grid Mount without Mounting Plate Suspended Ceiling Grid: You may attach the WAP directly to a 15/16” ceiling grid without using a mounting plate. There are two ceiling grid tabs on the back of the WAP, indicated in blue in the photo.
- Page 9 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Use the three screws provided in the accessory kit to attach the locking plate to the WAP mounting plate as shown. NOTE: Use only the screws provided in the accessory kit.
- Page 10 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Align the WAP mounting plate over the screw posts of the T- Bar clips or bracket and secure it to the four posts using the nuts provided. Tighten the nuts to 10-12 lbf.ft (1.38-1.66 kgf.m), but do not over tighten.
- Page 11 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series NOTE: Steps 1 and 2 are only required if you wish to lock the WAP to its mounting plate after it is installed. Align the three holes in the locking plate over the corresponding three holes in the WAP mounting plate.
- Page 12 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Align the two slots in the back of the WAP chassis shown here with the corresponding tabs in the WAP mounting plate. Push the WAP chassis up on the mounting plate tabs and rotate the WAP to the right until it snaps in place.
- Page 13 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Cut an access hole for the cable in the wall and draw the cable(s) through. Align the two slots in the back of the WAP chassis shown here with the corresponding tabs in the WAP mounting plate.
- Page 14 WOS. Newly discovered WAPs are automatically assigned to the WOS “default” profile, and will receive the configuration defined for that profile. If you are not using WOS, please refer to Using the Avaya OS for Avaya WLAN AP 9100 Series (NN47252-102) to configure your WAP manually via the Express Setup menu option.
- Page 15 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Using the Reset Button The reset button returns the WAP to factory default settings while rebooting. It is located in a small hole on the bottom of the unit next to the slot for the locking slug, opposite the side with the Gigabit ports as shown.
- Page 16 Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Drawings WAP912X/WAP913xX Mounting Bracket Wall Mounting Bracket...
-
Page 17: Direct Mounting Template
Installing the Avaya WLAN Indoor Access Points WAP912X and WAP913X Series Direct Mounting Template Physical/Environmental Specifications Dimensions (WxDxH): 7.70 x 7.70 x 1.96 in / 19.56 x 19.56 x 4.98 cm Weight: 1.6 lb / 0.73 kg ...
