INSTALLATION INSTRUCTION SUPPLEMENT
EXTREME
WITH SELF-DIAGNOSTICS OPTION
SERIES LVS 120/277 ELN SD and LVS2 120/277 ELN SD
CAUTION: For safety and proper operation, read and follow instructions carefully before installation.
U.S. Patent No. D383,501
Important Note: This Instruction sheet supple-
ment is to be used in conjunction with the Installa-
tion Instructions provided with the unit.
EMERGENCY LIGHTING SYSTEMS
TEL: 800-334-8694 Fax: 770-981-8141 www.lithonia.com
®
LED EMERGENCY EXIT SIGNS
IMPORTANT SAFEGUARDS
1.READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
2. Before wiring to power supply, turn off electricity at fuse or circuit
breaker.
3. Disconnect A.C. power and Power Plug before servicing.
4. Refer to wiring diagram sheet for proper connections.
5. Be sure unit is wired to AC power before power plug is connected.
6. All servicing should be performed by qualified personnel.
7. Consult your local building code for approved wiring and
installation.
8. Do not use outdoors.
9. Do not mount near gas or electric heater.
10. Fixture must be grounded to avoid potential electric shock.
11. Equipment should be mounted in location and at heights where it
will not readily be subjected to tampering by unauthorized
personnel.
12. The use of accessory equipment not recommended by the
manufacturer may cause an unsafe condition.
13. Do not use this equipment for other than intended use.
SAVE THESE INSTRUCTIONS
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Lithonia Lighting EXTREME LVS2 120/277 ELN SD Series
Summary of Contents for Lithonia Lighting EXTREME LVS2 120/277 ELN SD Series
-
Page 1: Safety Instructions
INSTALLATION INSTRUCTION SUPPLEMENT ® EXTREME LED EMERGENCY EXIT SIGNS WITH SELF-DIAGNOSTICS OPTION SERIES LVS 120/277 ELN SD and LVS2 120/277 ELN SD CAUTION: For safety and proper operation, read and follow instructions carefully before installation. IMPORTANT SAFEGUARDS 1.READ AND FOLLOW ALL SAFETY INSTRUCTIONS 2. - Page 2 PARTS DESCRIPTION Charger PC Board Self-Diagnostics PC Board Pushnut Connectors Battery Battery Connector Lamp Connector Cable Self-Diagnostics Harness (to Test Switch/ Status Indicator connector) Self-Diagnostics Harness (to Charger PCB) Lampboard Manual Test Switch Test Switch/Status Indicator Connector Magnetic Test Switch Lamp Connector Charger Board/Self-Diagnostics Connections Figure A...
- Page 3 PARTS DESCRIPTION Charger PC Board Self-Diagnostics PC Board Pushnut Connectors Battery Battery Cable Lamp Connector Cable Self-Diagnostics Harness (to Test Switch/Status Indicator connector) Self-Diagnostics Harness (to Charger PCB) Lampboard Manual Test Switch Test Switch/Status Indicator Connector Magnetic Test Switch Lamp Connector Charger PCB/Self-Diagnostics connections Figure B Dual Face Exit...
- Page 4 Self Diagnostics Testing: Manually Clearing a Failure: Important Note: Emergency lighting systems should be A failure indication may be cleared manually by: tested as often as local codes require, or at least monthly, to 1. Placing the unit in the manual test mode for more than 30 ascertain that all components are operational.
