2

Technical data

2.1 Unit data

Series
Power supply
Current load (heating cycle pump)
Probe
Accuracy
Set the temperature
Temperature display
Ambient temperature
Humidity (non-condensing)
Storage temperature
Current consumption
Timing error
Housing
Suitable flush-mounted socket
Wire clips
Enclosure class
Keys
We reserve the right to make technical changes for the purpose of technical advancement.

2.2 Unit dimensions

50
A
90
Fig. 1: Dimensions (all measurements in mm)
A: Front view
B: Side view
V/Hz
A
°C/F
°C
°C
°C
% rel. hum.
°C
W
%
mm
2
mm
14
B
24
14
C: Rear view
Easy-Control EC1
230 AC, 50
3
NTC3950, l0K
± 0.5/± 1
5-35
5-99
0-45
5-95
5-45
< 1.5
< 1
PC +ABS (fire-resistant)
86 x 86 square or European 60 mm
round box
Wire 2 x 1.5 or 1 x 2.5
IP30
Capacitive touch keys
86
60 (±2)
C
50
7
