The Pool Factory Saltwater Aurora Installation Manual page 23

Section
1
1. Bottom plates - straight section
a. Screw the bottom plate on the strap end channel with a
#10-1" screw (99-0070). The bottom plate has to sit on
the edge of the strap end channel and the steel upright.
(Images 24 to 26)
b. The installation of the bottom plates for the round section
will continue in Section 2.
Proceed to the next step, Measuring for the buttress
trenches.
Helpful Hint:
Do not be alarmed if you are not using all of the holes in
the strap end channels.
Section 1
GENERAL INSTRUCTIONS - OVAL POOLS
GROUND PREPARATION
C. CONT. PRE-ASSEMBLY OF THE STRAIGHT SECTION
No Diving or Jumping. Observe all Safety Rules
24
25
26
Page 23
