The Pool Factory Saltwater Aurora Installation Manual page 22

Section
1
i. Place a top plate on the top of each of the pool steel
structures. The holes of the top plate and steel structure
must be aligned and screwed on the side using three
#10-1/2" screws (99-0068). (Image 21)
NOTE: Be sure to verify your pool's footprint to
ensure correct strap lengths.
j. Slide a strap under the front part of a channel, the two
holes in these End Channel Caps will line up with the two
holes in the straps. (Image 22)
k. The End Channel Caps are secured in place using the
same two 5/16" x 1/2" screws (99-0026) and 5/16" nuts
(99-0027) that are used to secure the straps to the strap
end channels. (Image 23)
Helpful Hint:
Do not be alarmed if you are not using all of the holes in
the strap end channels.
GENERAL INSTRUCTIONS - OVAL POOLS
GROUND PREPARATION
C. CONT. PRE-ASSEMBLY OF THE STRAIGHT SECTION
No Diving or Jumping. Observe all Safety Rules
21
22
23
Page 22
Section 1
