The Pool Factory Saltwater Aurora Installation Manual page 19

Section
1
Section 1
GENERAL INSTRUCTIONS - OVAL POOLS
GROUND PREPARATION
C. PRE-ASSEMBLY OF THE STRAIGHT SECTION-Yardmore Hardware
(99-0026)
1/2"-5/16
Screw
(V12x34)
#12–3/4"
Screw
(99-0026)
1/2"–5/16"
Screw
(99-0027)
5/16"
Nut
(V12x34)
#12–3/4"
Screw
(99-0068)
#10–1/2"
Screw
(99-0027)
5/16"
Nut
(99-0027)
5/16"
Nut
(16663)
3 Hole Washer
No Diving or Jumping. Observe all Safety Rules
(99-0027)
5/16"
Nut
(99-0068)
#10–1/2"
Screw
(99-0027)
5/16"
Nut
(99-0070)
#10–1"
Screw
(99-0068)
#10–1/2"
Screw
(2PCB520) 5 1/2" x 1/4-20 Bolt
Page 19
(99-0073)
5/16–5"
Bolt
(99-0070)
#10–1"
Screw
(99-0027)
5/16"
Nut
(99-0073)
5/16–5"
Bolt
(99-0073)
5/16–5"
Bolt
