Altronix TROVE T1RAG3F8 Installation Manual page 2

Altronix Trove rtack AMAG kit is pre-assembled and consist of Trove rack enclosures/backplane with factory installed Altronix power
supply/charger and sub-assemblies. Kits accommodate up to two (2) AMAG M4000 modules for up to eight (8) doors in a single enclosure.
120VAC
Altronix 60Hz
Model Input
Number Current
T1RAG3F8
3.5A
Assembling and Attaching Z Bracket Wire Management Accessory (included):
Altronix Trove Rack enclosures include Z Bracket, a convenient and reliable wire management accessory.
Hardware (included):
Ten (10) bolts and
1. Carefully unpack Z Bracket. Do not discard hardware (included)
(Fig. 1, pg. 2).
2. Attach arms to each other using bolts and
lock nuts (Fig. 1a, pg. 2).
3. Attach the hinge brackets to the ends of
arms using bolts and nuts positioning
them as shown on Fig. 1b, pg. 2.
4. Make sure that all nuts are tightened.
5. Attach the hinge bracket on the longer side of Z Bracket to the adjustable slide using bolts and lock nuts (included) (Fig. 2, 2a, pg. 2).
6. Attach the hinge bracket on the shorter side of Z Bracket to the rear of the rack enclosure using bolts (included).
Fig. 2
- 2 -
Configuration Chart:
Output Voltage
Power Power
[DC]
Supply Supply
Board Board
Input Battery Output
Fuse Fuse Range
Rating Rating (VDC)
15A/ 20.17-
5A/250V
32V 26.4
eight (8) lock nuts.
Fig. 1a
Overview:
Nominal DC
Maximum Supply
Current for Main and
[Aux]
Aux. Outputs on
Power Supply board
Output and ACMS8 Access
Range Power Controllers'
(VDC) outputs
20.28-
24VDC @ 5.4A
26.4
Fail-Safe/ ACMS8
Fail-Secure Board
or Dry Form Input Fuse
"C" Outputs Rating
15A/
8
32V
Fig. 2a
ACMS8
Board
Output Fuse
Rating
3A/
32V
Fig. 1
Two (2)
Fig. 1b
Trove1AG1R
