Summary of Contents for Lenze g700 Series
- Page 1 g700 g700−P20 ... g700−P800 | 5 Nm ... 800 Nm Mounting Instructions Planetary gearboxes with servo...
- Page 2 First read this documentation and the documentation of the motor before you start working. Observe the safety instructions contained therein. 0Abb. 0Tab. 0...
-
Page 3: Table Of Contents
..........Lenze ¯ MA 12.0015 ¯ 1.0... -
Page 4: About This Documentation
Qualified skilled personnel are persons who have the required qualifications to carry out all activities involved in installing, mounting, commissioning, and operating the product. Tip! Information and auxiliary devices related to the Lenze products can be found in the download area at http://www.Lenze.com Document history... -
Page 5: Terminology Used
In the following text used for Gearboxes Gearbox of the product family g700 Drive system Drive systems with g700 gearboxes and other Lenze drive components Notes used The following pictographs and signal words are used in this documentation to indicate... -
Page 6: Safety Instructions
This is vital for a safe and trouble−free operation and for achieving the specified product features. ¯ Only qualified skilled personnel are permitted to work with or on Lenze drive and automation components. According to IEC 60364 or CENELEC HD 384, these are persons ... -
Page 7: Product Description
Technical data 16.1 Motor speed [rpm] motor 16.2 Perm. output speed for S1 operation [Hz] 16.3 Motor code for controller parameterisation (code 0086) 16.4 Temperature monitoring Weight Year / week of manufacture UL file number Lenze ¯ MA 12.0015 ¯ 1.0... -
Page 8: Transport Weights
< 10.0 < 13.0 g700−P260 < 13.0 < 18.0 < 17.0 < 25.0 < 22.0 < 31.0 < 36.0 g700−P800 < 37.0 < 13.0 < 51.0 < 48.0 < 70.0 Tab. 1 Weights in kg Lenze ¯ MA 12.0015 ¯ 1.0... -
Page 9: Mechanical Installation
The motors attached to the gearbox are partially equipped with eyebolts. These are exclusively determined for mounting/dismounting the motor to the gearbox and must not be used for the complete geared motor! Stop! Observe load carrying capacity! Staying under floating load is prohibited! Lenze ¯ MA 12.0015 ¯ 1.0... -
Page 10: Preparation
Note! The notes for the electrical connection can be found in... ¯ in the terminal box (in case of motors with terminal box). ¯ in the connection plan (in case of motors with plugs). Lenze ¯ MA 12.0015 ¯ 1.0... -
Page 11: Commissioning And Operation
– the condition of the electrical cables. ¯ In case of faults: – shut down the drive, – check the troubleshooting table. If the fault cannot be remedied, please contact the Lenze customer service. Lenze ¯ MA 12.0015 ¯ 1.0... -
Page 12: Maintenance
¯ The gearboxes are lubricated for life. ¯ The mechanical power transmission system is maintenance−free. Repair ¯ We recommend that all repairs are carried out by the Lenze customer service. Disposal Protect the environment! Packing material can be recycled. Dispose of your separated resources according to the waste disposal regulations or via a waste management company. -
Page 13: Troubleshooting And Fault Elimination
If any malfunctions should occur during operation of the drive system, please check the possible causes using the following table. If the fault cannot be eliminated by one of the listed measures, please contact the Lenze Service. Fault Possible cause... - Page 14 Inadequate alignment of Realign machine unit, check foundation if drive train necessary Loose fixing screws Check and tighten screw connections Running noises Foreign particles inside the Repair by manufacturer if necessary motor Bearing damage Lenze ¯ MA 12.0015 ¯ 1.0...
- Page 15 Notes Lenze ¯ MA 12.0015 ¯ 1.0...
- Page 16 © 03/2014 | MA 12.0015 | .O10 | 1.0 | TD09 Lenze Drives GmbH Postfach 10 13 52 D−31763 Hameln Germany Ü +49 5154 82−0 Ø +49 5154 82−2800 Ù Lenze@Lenze.com Ú www.Lenze.com Û Lenze Service GmbH Breslauer Straße 3 D−32699 Extertal...
