Introduction to the SENTOSA xi xi xi xi xi LQ & LANCIA xi xi xi xi xi LD
Features unique to the Lanciaxi xi xi xi xi LD include the following.
• Line doubler - Doubles the resolution of standard video from 525
interlaced lines at 15 kHz to 525 non-interlaced lines at 31.5 kHz for
a clearer, brighter output.
• Demo-mode - Built-in "demo mode" allows split screen of video
and line doubled video side by side.
• VGA mode - Conveniently converts video signals to 480 lines of
non-interlaced VGA. This VGA output allows you to plug directly
into digital display devices for RGBHV signal transmission.
Features of Sentosaxi and Lanciaxi include the following.
• Quad-standard decoder - Sentosaxi and Lanciaxi are compatible
with all international video formats including NTSC 3.58, NTSC
4.43, PAL and SECAM.
• Motion mode compensation - With motion mode compensation,
the Sentosaxi and Lanciaxi virtually eliminate the "jaggies" found in
line quadrupled or line doubled video.
• Picture controls - Picture controls include color, hue (tint),
horizontal shift and contrast for each input. The Sentosaxi and
Lanciaxi will save picture controls for each of the two inputs.
• RS-232 control - A rear panel RS-232 serial port provides access
for a third-party remote control system.
• Input sync detection - In auto-switch mode the input with a signal
present is automatically selected, perfect for the video loop-back
feature of the System 8 and 10 PLUS switchers.
• Universal compatibility - Outputs either RGsB, RGBS or RGBHV
signals at 31.5 kHz for the Lanciaxi and 63 kHz for the Sentosaxi.
• Output sync polarity - Sync polarity can be adjusted through rear
panel DIP switches (positive or negative H&V) to allow for any
projector to recognize the Sentosaxi or Lanciaxi input versus a
standard VGA input and save different convergence, brightness
and contrast settings.
• Rack mountable - The Sentosaxi and Lanciaxi fit into a 1U high,
1/2 rack width metal enclosure.
