2 Display
Icon: Meaning:
Rechargeable battery level indicator
You are online
There are new messages in your voice mail
New numbers in call list
The keypad is locked
Microphone is muted
Memory records are being retrieved or set up
When ring buzzer is turned off
The antenna indicates the quality of reception.
The antenna blinks when the handset is out of range!
There are more digits on the left
There are more digits on the right
Scroll direction in the menu
BE300 - x x = handset number
3 Installation
3.1 Base
• Plug one end of the phone cable into the phone unit and the other end into the telephone
line wall socket.
• Connect the small plug of the AC adaptor to the phone and the other end of the adapter
cable to the electric socket.
Topcom Butler ME300/Twin/Triple/Quattro
Topcom Butler E300/Twin/Triple/Quattro
Telephone cord
Power cable
Telephone socket
3
