CALCulate:MATH

CALCulate:MATH <expression>, (@<computed_ch_list>)
CALCulate:MATH? (@<computed_ch_list>)
A computed channel performs mathematical operation on the readings from measurement channels, or other com-
puted channels list. Selects type of < expression > to specify the mathematical operation, and the operand channels
that are used for computing.
Only supported on computed channels (channels 401 through 420).
Computation type Mathematical operation
Basic math Add
Subtract
Multiply
Divide
Power
Square root
Reciprocal
Polynomial Fifth order
Statistics Min
Max
Sum
Average
Standard deviation
Basic math examples:
Selects math operation (add), and operand channels (channel 101 and 102) that are used for computing in channel
401:
CALC:MATH (@101+@102),(@401)
Typical response: "(@101+@102)"
In this example, you can replace the (@101+@102) with (@101-@102), (@101*@102), and (@101/@102) for
subtract, multiply, and divide operations.
Selects math operation (power), and operand channels (channel 101) that are used for computing in channel 401:
CALC:MATH (power(@101, 2)),(@401)
Typical response: "(power(@101, 2))"
Keysight DAQ970A/DAQ973A Programming Guide
Parameter (< expression >)
(@chan1+@chan2)
(@chan1-@chan2)
(@chan1*@chan2)
(@chan1/@chan2)
(power(@chan1, 2))
(sqrt(@chan1))
(1/@chan1)
(poly(@chan1, <n5>, <n4>, <n3>, <n2>, <n1>, <n0>))
where n = value of variable in each order
(min(@<ch_list>))
(max(@<ch_list>))
(sum(@<ch_list>))
(avg(@<ch_list>))
(sdev(@<ch_list))
2 SCPI Programming
Typical return
(none)
