SOURce:MODE:LOCK {OFF | ON}, (@<ch_list>)
SOURce:MODE:LOCK? (@<ch_list>)
Enables (On) or disables (Off) the locking of the DAC output channel mode (voltage or current). When enabled, the
output mode cannot be changed without disabling the lock.
Only supported on DAQM907A multifunction module (DAC output channels).
Parameter
{OFF | ON}.
Default: OFF
Enables locking of the DAC output mode: SOUR:MODE:LOCK ON
– On - Output mode is unlocked.
– Off - Output mode is locked.
– Locking mode stored on the module in non-volatile memory.
– DAC output mode is set to voltage (if it is unlocked with
is locked to current with
SOURce:VOLTage {<voltage> | MIN | MAX | DEF}, (@<ch_list>)
SOURce:VOLTage? {(@<ch_list>) | MIN | MAX | DEF}
Sets the output mode in DAC output channels (channel 04 and 05) to voltage.
Only supported on DAQM907A multifunction module (DAC output channels).
Parameter
<voltage>
MIN: -12 VDC
DEF: 0 VDC
MAX: +12 VDC
Command outputs +2.5 VDC on DAC output channels 04 and 05 in slot 2:
SOUR:VOLT 2.5, (@204,205)
OUTP:STAT ON, (@204,205)
– This parameter is set to its default value after a Factory Reset
Keysight DAQ970A/DAQ973A Programming Guide
Typical return
0 (OFF) or 1 (ON)
SOUR:MODE:LOCK ON
Typical return
+2.5.00000000E+0
SOUR:MODE:LOCK OFF
command, an error will be generated.
(*RST command).
2 SCPI Programming
command). If the output mode
