- Page 1 Security Guide Keysight DAQ970A Data Acquisition System...
-
Page 2: Table Of Contents
Notices Copyright Notice Manual Part Number Edition Published by Software Revision Warranty Technology Licenses Restricted Rights Legend Waste Electrical and Electronic Equipment (WEEE) Declarations of Conformity Safety Information Warranty Where to find the latest information Is your product software up-to-date? Contacting Keysight Sales and Service Offices Products Covered by this Document Document Purpose... -
Page 3: Notices
No part of this manual may be reproduced in any form or by any means (including electronic storage and retrieval or translation into a foreign language) without prior agreement and written consent from Keysight Technologies as governed by United States and international copyright laws. -
Page 4: Technology Licenses
(June 1987) or any equivalent agency regulation or contract clause. Use, duplication or disclosure of Software is subject to Keysight Technologies’ standard commercial license terms, and non-DOD Departments and Agencies of the U.S. Government will receive no greater than Restricted Rights as defined in FAR 52.227-19(c) (1-2) (June 1987). -
Page 5: Safety Information
Do not proceed beyond a WARNING sign until the indicated conditions are fully understood and met. The NOTE sign denotes important information. It calls attention to a procedure, practice, condition or the like, which is essential to highlight. Keysight DAQ970A Security Guide... -
Page 6: Warranty
This Keysight Technologies product is warranted against defects in material and workmanship for a period of one year from the date of shipment. During the warranty period, Keysight Technologies will, at its option, either repair or replace products that prove to be defective. For warranty service or repair, this product must be returned to a service facility designated by Keysight Technologies. -
Page 7: Contacting Keysight Sales And Service Offices
If you do not have access to the Internet, please contact your field engineer. In any correspondence or telephone conversation, refer to the instrument by its model number and full serial number. With this information, the Keysight representative can determine whether your unit is still within its warranty period. Keysight DAQ970A Security Guide... -
Page 8: Products Covered By This Document
Be sure that all information stored by the user in the instrument that needs to be saved is properly backed up before attempting to clear any of the instrument memory. Keysight Technologies cannot be held responsible for any lost files or data resulting from the clearing of memory. Be sure to read this document entirely before proceeding with any file deletion or memory clearing. -
Page 9: Security Terms And Definitions
Keysight Technologies's memory sanitization procedures are designed for customers who need to meet the requirements specified by the US Defense Security Service (DSS). These requirements are specified in the “Clearing and Sanitization Matrix”... -
Page 10: Instrument Memory
By factory Mainframe Not available (FRAM) execution code. install and by 8.5 kByte firmware upgrade Keyboard Pro- Used to store processor By factory Mainframe Not available cessor (FRAM) execution code. install and by 8.5 kByte firmware upgrade Keysight DAQ970A Security Guide... - Page 11 Contains logic array By factory Measurement Not available FPGA (Flash) configuration. install and by board 1.27 Mbit firmware upgrade Measurement Used for data processing. By FPGA oper- Measurement Power cycle FPGA (SRAM) ations board 166 kbit Keysight DAQ970A Security Guide...
-
Page 12: Summary Of Memory Declassification Procedures
To remove files and folders from the file system, send below commands: MMEMory:DELete <file> MMEMory:RDIRectory <folder> For more information, see DAQ970A Programming Guide. Memory sanitization This memory can be sanitized by following the instructions in . The model number, FPGA Secure Erase All configuration image and the instrument firmware are retained. - Page 13 Manual (NISPOM). This command is for users, such as military contractors, who must comply with NISPOM. Specially, the action will fully declassify all non-volatile memory using the methods specified in the June 28, 2007 DSS Memory Clearing and Sanitization Matrix. Memory removal Not available Memory validation Not available Keysight DAQ970A Security Guide...
-
Page 14: Memory Sanitization Procedure
Executing this operation will increment the instrument’s secure count. This procedure should be performed only when the instrument is to be removed from a secure area. Front panel Remote interface Press [Utility] > Security > Secure On > NISPOM Sanitize > Sanitize SYSTEM:SECurity:IMMediate Keysight DAQ970A Security Guide... -
Page 15: User And Remote Interface Security Measures
To defeat or override an instrument’s administrative password (calibration secure override/Security option override) follow the procedure in the DAQ970A Service Guide . This involves removing power and other connections to the instrument, removing the instrument cover (requires tools), shorting a jumper and cycling power. The calibration count and secure count will increase when the password is defeated using this method. -
Page 16: Front Panel Usb Host Port
How to disable the front panel during remote operation To programmatically lock out all front panel operation and remote access over the current interface, use the SYSTem:LOCK command. For more information, see DAQ970A Programming Guide . Calibration regulation The instrument requires a password to unsecure the instrument before performing calibration. The instrument’s calibration count will increment with each successful calibration step. -
Page 17: Procedure For Declassifying A Faulty Instrument
DSS/NISPOM approved destruction method. Refer to the procedures in DAQ970A Service Guide for removing the front panel circuit assembly. Send the instrument to a Keysight repair facility. If the unit is still under warranty, the repair facility will replace the front panel printed circuit assembly. -
Page 18: References
2. ISFO Process Manual for the Certification and Accreditation of Classified Systems under the NISPOM Defense Security Service. DSS-cleared industries may request a copy of this document via email, by following the instructions at: http://www.dss.mil/isp/odaa/request.html Keysight DAQ970A Security Guide... - Page 19 This information is subject to change without notice. © Keysight Technologies 2018 Edition 1, July 2018 Printed in Malaysia DAQ97-90003 www.keysight.com...
