[SENSe:]STRain:VOLTage:RANGe {<range> | MIN | MAX | DEF} [, (@<ch_list>)]
[SENSe:]STRain:VOLTage:RANGe? [{(@<ch_list>) | MIN | MAX | DEF}]
Selects a fixed voltage range for strain measurements.
This parameter setting is not shared between AC and DC measurements. The parameters are independent for
AC and DC measurements.
Parameter
<range> = {0.1 | 300 | 0.1}
Default = 0.1
– Selecting a fixed range ([SENSe:]< function >:RANGe) disables autoranging.
– If the input signal is greater than can be measured on the specified fixed range, the instrument displays Overload
on front panel and returns "9.9E37" from the remote interface.
– This parameter is set to its default value after a Factory Reset
[SENSe:]STRain:ZERO:AUTO {OFF | ON} [, (@<ch_list>)]
[SENSe:]STRain:ZERO:AUTO? [(@<ch_list>)]
Enables or disables the autozero mode for strain measurements.
Parameter
{OFF | ON}
Default: ON
– ON (Default): Internally measures the offset following each measurement. It then subtracts that measurement
from the preceding reading. This prevents offset readings present on the instrument's input circuitry from affect-
ing measurement accuracy.
– OFF: The instrument uses the last measured zero measurement and subtracts it from each measurement. It
takes a new zero measurement each time you change the function, range or integration time.
– The autozero mode is set indirectly when you set the resolution and integration time with CONFigure and
MEASure? commands. Autozero is automatically turned OFF when you select an integration time less than 1 PLC
with these commands.
– This parameter is set to its default value after a Factory Reset
Keysight DAQ970A/DAQ973A Programming Guide
Typical return
+1.00000000E+01
Typical return
0 (OFF) or 1 (ON)
(*RST command).
(*RST command).
