Introduction

Basic System Configuration

For your satellite TV system to work properly, the system will have to
be connected with all of the provided components properly, as shown
in the figure below (Refer to next chapter 'Installation' in this manual
for more detailed connection instructions). Separate purchase of a
satellite receiver and a TV is required.
TV (Not Supplied)
IRD1 (Not Supplied)
RF Cable
DC Power Cable
[i9P System Diagram]
(Optional)
IRD2 (Not Supplied)
(Optional)
IRD3 (Not Supplied)
(Optional)
IRD4 (Not Supplied)
Power & Data Cable
NMEA
PC Cable
GPS
3
