Basic System Configuration of Intellian i2

TV TV
(Not Supplied) (Not Supplied)
For your satellite TV system to function properly, the system will have to
be connected with all of the provided components as shown on the right
(Refer to the next chapter 'Installation' in this manual for more detailed
connection instructions). Separate purchase of a satellite receiver and a
TV is required.
Satellite Receiver Satellite Receiver
(Not Supplied) (Not Supplied)
Note: Dish Network and Bell TV users please refer to the Intellian Dish
Network MIM Installation and User Manual.
Antenna Control Unit
PC( Not Supplied)
DC Power on Vessel NMEA GPS
(DC - 9.0 - 30.0V)
Figure 01 : Basic Configuration with 2 Receivers
