Section 2 – System overview
2.1 RD7000+ locator
2.1.1 Locator features
1.
Keypad.
2.
LCD with auto backlight.
3.
Speaker.
4.
Battery compartment.
5.
Accessory slot.
6.
Headphone jack.
2.1.2 Locator keypad
7.
Power key
: Switches the unit on and off.
Opens the locator menu.
8.
Frequency key
: Selects frequency.
Closes submenu.
9.
Up and down arrows
Scrolls through the menu options.
10.
Antenna key
: Toggles peak, null (PL and TL
models only) and combined peak/null modes.
Open submenu. Prolonged keypress toggles
between depth or current display on the LCD.
2.1.3 Locator screen icons
11.
Indicates the signal strength and peak marker.
12.
Signal strength: Numeric indication of signal strength.
13.
Peak arrows: Indicates the location of the line relative
to the locator.
14.
Battery icon: Indicates the battery level.
15.
Volume icon: Displays the volume level.
16.
Fault-Find arrows (PL and TL models only)
17.
Radio Mode: Indicates when Radio Mode is active.
18.
Power Mode: Indicates when Power Mode is active.
19.
Accessory indicator: Indicates when an accessory is
connected.
20.
A-Frame icon: Indicates when the A-Frame is
connected.
21.
Operating mode indicator.
: Adjusts the signal gain.
22.
Compass: Shows the direction of the located cable
relative to the locator.
23.
Null / Peak icon: Indicates antenna selection.
24.
Sonde icon: Indicates that the signal source is from
a sonde.
25.
Line icon: Indicates that the signal source is from
a line.
26.
Current / depth indicator.
RD7000+ Operation Manual 3
