2.2 Tx-1, Tx-3 and Tx-10
transmitters
2.2.1 Transmitter features
1.
Keypad.
2.
LCD.
3.
Removable accessory tray.
4.
Rechargeable battery pack.
2.2.2 Transmitter keypad
5.
Power key
: Switches the unit on and off. Opens
the transmitter menu.
6.
Frequency key
: Selects frequency. Menu
navigation key.
7.
Up and down arrows
signal. Scrolls through the menu options.
8.
Measure key
: Toggles measurement display
between volts, current and impedance.
Note: displayed measurements are based on the
currently selected mode or the attached accessory,
if applicable. Opens a submenu.
2.2.3 Transmitter screen icons
9.
Battery icon: Indicates the battery level.
10.
Alphanumeric description of selected operation mode.
11.
Standby icon: Appears when the transmitter is in
Standby Mode.
12.
Output level: Displays transmitter output power.
13.
Clamp icon: Indicates when a clamp or other plug is
connected.
14.
DC icon: Appears when the transmitter is powered
from a DC source.
15.
Induction indicator: Appears when the transmitter is
in Induction Mode.
16.
A-Frame (Tx-3 and Tx-10 only): Indicates when the
transmitter is in Fault-Find Mode.
17.
CD Mode indicator (Tx-10 only): Indicates that the
transmitter is in Current Direction Mode.
18.
Voltage warning indicator: Indicates that the
transmitter is outputting potentially hazardous
voltage levels.
19.
Volume icon: Displays the volume level.
20.
Pairing icon (Tx-3B and Tx-10B only). For use with
RD8000 locators only.
21.
Bluetooth
icon (Tx-3B and Tx-10B only). For use
®
with RD8000 locators only.
: Adjusts the output
RD7000+ Operation Manual 5
