AMD K6 CPU Settings

AMD K6 – 166/200/233
AMD K6
CPUs
JP1
1 2 JP2
1 2
5 6
11 12
AMD K6 – 166 AMD K6 – 200
JBF3
JBF2
JBF1
JP1 JP1
1 2 1
11 12 11
(2.9V) (2.9V)
Figure 2Ð2. CPU Type Configuration
Note: K6Ð233 CPU is 3.2V or 2.1V depending on its prcess.
Please check its spec before using it.
1
JBF3
JBF2
JBF1
AMD K6 – 233
JBF3 JBF3
JBF2 JBF2
JBF1 JBF1
JP1
2 1 2
12 11 12
(3.2V)
Hardware Installation 7
