Notice to End Users
This UserÕs Guide & Technical Reference is for assisting system
manufacturers and end users in setting up and installing the
mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for
printing or clerical errors. Information in this document is subject
to change without notice and does not represent a commitment on
the part of Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for
identification purposes only. Product names appearing in this
manual may or may not be registered trademarks or copyrights of
their respective companies.
S
C
I
.
OLTEK
OMPUTER
NC
PROVIDES THIS MANUAL
WITHOUT WARRANTY OF ANY KIND
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A
. I
PARTICULAR PURPOSE
N NO EVENT SHALL
I
.
NC
BE LIABLE FOR ANY LOSS OR PROFITS
,
OF USE OR DATA
INTERRUPTION OF BUSINESS
,
,
SPECIAL
INCIDENTAL
OR CONSEQUENTIAL DAMAGES OF ANY
,
S
C
KIND
EVEN IF
OLTEK
OMPUTER
POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR
ERROR IN THIS MANUAL OR PRODUCT
© Copyright 1998 Soltek Computer Inc. All right reserved
Web site: http://www.soltek.com.tw
email:
support@mail.soltek.com.tw
Edition: August 1998
Version: 1.0
SL-56D5/D1 SERIALS
Ò
Ó
AS IS
,
,
EITHER EXPRESS OR IMPLIED
S
C
OLTEK
OMPUTER
,
,
LOSS OF BUSINESS
LOSS
,
,
OR FOR INDIRECT
I
.
NC
HAS BEEN ADVISED OF THE
.
®
i
Advertisement
Table of Contents
Related Manuals for SOLTEK SL-56D1
Summary of Contents for SOLTEK SL-56D1
- Page 1 Every effort has been made to ensure that the information in this manual is accurate. Soltek Computer Inc. is not responsible for printing or clerical errors. Information in this document is subject to change without notice and does not represent a commitment on the part of Soltek Computer Inc.
-
Page 2: Table Of Contents
Contents Chapter 1: Introduction --------------------------------------- 1 Features ------------------------------------------------------------------------- 1 CPU ------------------------------------------------------------------------ 1 Chipset -------------------------------------------------------------------- 1 L2 Cache ------------------------------------------------------------------ 1 Main Memory ----------------------------------------------------------- 1 BIOS ------------------------------------------------------------------------ 2 I/O Function ------------------------------------------------------------- 2 Other Functions --------------------------------------------------------- 2 Mainboard Setting for Pentium MMX-200----------------------------- 3 Chapter 2: Hardware Setup ---------------------------------- 5 CPU VCORE Voltage Setting---------------------------------------------- 5 JP4: CPU VCore Voltage Setting ----------------------------------- 5... - Page 3 IDE LED Activity Light: (J1 pin1Ð4)------------------------------ 15 Infrared Port Module Connector (J1 pin6Ð10) ----------------- 15 J1 pin12, 13: ATX Power Button ---------------------------------- 15 J1 pin14, 15: Reserved ----------------------------------------------- 15 Speaker Connector (J2 pin1Ð4) ------------------------------------ 15 Reset Switch (J2 pin5, 6)--------------------------------------------- 16 Power LED and Keylock Switch (J2 pin8Ð12)------------------ 16 JWOL1: Wake On Lan (WOL) Connector ---------------------- 16 Turbo LED (J2 pin14, 15)-------------------------------------------- 17...
-
Page 5: Chapter 1: Introduction
Chapter 1 Introduction Features 1. Supports Intel Pentium MMX CPUs at 100 ~ 233 MHz; 2. Supports Cyrix 6x86(L) CPUs at PR133 + ~ PR200 + MHz and 6x86MX (MII) CPUs at PR166 + ~ PR350 + MHz; 3. Supports AMD K5: PR100 ~ PR200MHz, AMD K6: 166 ~ 333MHz, and AMD K6-2: 250 ~ 350MHz;... -
Page 6: Bios
BIOS 1. AWARD Plug and Play BIOS; 2. Supports Advanced Power Management, ACPI Function; 3. Flash Memory for easy upgrade. I/O Function 1. Integrated USB (Universal Serial Bus) controller with two USB ports; 2. Supports 2 IDE channels with 4IDE devices (including 120MB IDE floppy);... -
Page 7: Mainboard Setting For Pentium Mmx-200
Mainboard Setting for Pentium MMX-200 The default settings of the following figure is for the INTEL Pentium MMX-200, Vcore: 2.8V. FAN1 Clock Gen. JP12 JP11 MMX-200 CPU PCI1 W83877F /877AF PCI2 JWOL1 PCI3 VT82C586B PCI4 Li BAT PCI5 ISA1 ISA2 Figure 1–1. -
Page 8: Chapter 2: Hardware Setup
Chapter 2 Hardware Setup CPU V Voltage Setting CORE JP4, JP11, JP12: CPU V Voltage Setting Core JP12 JP12 JP12 Core Core Core Voltage JP11 Voltage JP11 Voltage JP11 2.2V 2.9V 2.8V K6-266 K6-166/200 (or higher) MMX, 6x86L 6x86MX/MII K6-2 JP12 JP12 JP12... -
Page 9: Agp Driver For Win95 Installation
Note: 1. Refer to the table above to choose the correct voltage for the CPU everytime that you install a CPU. 2. Make sure that your JP4 is matched with the CPU voltage, otherwise will damage the CPU or make the system unstable. 3. -
Page 10: Intel Pentium Mmxð166/200/233 Cpus
ÒHKEY_LOCAL_MACHINES\System\CurrentControlSet\ Services\VxDÓ. Follow the below procedure to check if the AGP driver is capable to activate: 1. Activate ÒControl Panel,Ó 2. Click ÒDirectX,Ó 3. Click ÒDirectDraw,Ó and 4. Check if there are some values in ÒBitÓ and ÒOverlays.Ó If there are some values, the AGP is able to activate. Intel Pentium MMX–166/200/233 CPUs MMX–166 MMX–200... -
Page 11: Amd K6 Cpu Settings
AMD K6 CPU Settings AMD K6 – 166/200/233 CPUs and K6-2 266 CPU K6-2-266 K6–200 K6–233 K6–300 K6–266 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 K6-2–266 K6–266/300 K6–200... -
Page 12: Amd K6-2 Ð 250/266/300/333/350 Cpu Settings
AMD K6-2 – 250/266/300/333/350 CPU Settings K6-2–250 K6-2–300 K6-2–350 K6-2–333 (100MHz x 2.5) (100MHz x 3.0) (100MHz x 3.5) (95MHz x 3.5) 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 AMD K6-2 CPUs... -
Page 13: Cyrix Mii Ð Pr300/333/350 Cpus
Cyrix MII – PR300/333/350 CPUs MII–300 MII–333 MII–350 (66MHz x 3.5) (100MHz x 2.5) (83MHz x 3.5) 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 MII–300 MII–333 MII–350 (75MHz x 3.0) (66MHz x 4.0) (100MHz x 3.0) 1 2 3 4 5 6... -
Page 14: Idt C6 Ð 200/225/240 Cpus
IDT C6 – 200/225 CPUs C6–200 C6–225 (66MHz x 3.0) (75MHz x 3.0) 1 2 3 4 5 6 1 2 3 4 5 6 IDT C6 CPUs (3.3V) Figure 2–5. CPU Type Configuration Hardware Installation 11... -
Page 15: Intel Pentium/Amd K5 Ð 133/166/200 Cpus
Intel Pentium/AMD K5 – 133/166/200 CPUs Pentium–166 Pentium–200 Pentium–133 K5–PR166 K5–PR200 K5–PR133 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6 Pentium/K5 CPUs (3.5V) Figure 2–6. CPU Type Configuration... -
Page 16: System Memory Configuration
System Memory Configuration This Apollo MVP3 motherboard supports 168pin DIMMs (3.3V unbuffered type) of 4MB, 8MB, 16MB, 32MB, or 64MB to form a memory size between 4MB to 768MB (total of 6 rows are supported). The Apollo MVP3 chipset supports ÒTable FreeÓ configuration so that DRAM module can be installed at any capacity. -
Page 17: Jp11, Jp12: Cpu Dual/Single Voltage Select
JP11, JP12: CPU Dual/Single Voltage Select JP11/JP12 CPU Type Single Pentium P54C, K5, Votage 6x86, IDT Dual MMX, 6x86L/6x86MX, Votage K6, K6-2, MII Note: Wrong setting of JP11/JP12 will damage the CPU. Please double check before powering on the system. SW1: 4~6: Bus Ratio Select SW1: 1~3: CPU Clock Setting Set the SW1 jumper according to your CPU Bus Ratio and... -
Page 18: Jp6, Jp7: Chipset Clock Settings
JP6, JP7: Chipset Clock Settings JP6, JP7 setting must depend on the CPU clock. The system will not boot up with wrong setting. JP7, JP6 Chipset Clock 66/75 MHz 83 MHz 95/100/112/ 124/133 MHz IDE LED Activity Light: (J1 pin1–4) This connector connects to the hard disk activity indicator light on the case. -
Page 19: Reset Switch (J2 Pin5, 6)
Reset Switch (J2 pin5, 6) The system board has a 2-pin connector for rebooting your computer without having to turn off your power switch. This prolongs the life of the systemÕs power supply. Power LED and Keylock Switch (J2 pin8–12) The keylock switch is a 5-pin connector for locking the keyboard for security purposes. -
Page 20: Turbo Led (J2 Pin14, 15)
Turbo LED (J2 pin14, 15) Connect the caseÕs turbo LED to this connector. HD LED IR CON KEYLOCK T/LED RESET HD/LED PWR/SW EXTSM1 RESET KEYLOCK T/LED Power Button HD/LED IR CON 9 10 12 13 14 15 9 10 11 12 14 15 Power Turbo... -
Page 21: J1 Switch Signal Summary
J1 Switch Signal Summary Signal Description HDD LED Connector HDD LED Signal HDD LED Signal N.C. No Connection Infrared Transmit Signal Infrared Connector Infrared Receive Signal (low speed) Infrared Receive Signal (high speed) No Connection Power Button (ATX ATX Power Button Power) N.C. -
Page 22: J2 Switch Signal Summary
J2 Switch Signal Summary Signal Description Speaker Signal Speaker Connector No Connection Ground Reset Switch Reset Signal Ground N.C. No Connection Power LED Connector No Connection Ground Keylock Connector Keylock Signal N.C. No Connection Turbo LED Connector Turbo LED Connector Ground Hardware Installation 19... -
Page 23: Chapter 3: Bios Setup
Chapter 3 Award BIOS Setup This VIA MVP3 motherboard comes with the AWARD BIOS from AWARD Software Inc. Enter the Award BIOS programÕs Main Menu as follows: 1. Turn on or reboot the system. After a series of diagnostic checks, the following message will appear: PRESS <DEL>... -
Page 24: Standard Cmos Setup
3. Using one of the arrows on your keyboard to select an option and press <Enter>. Modify the system parameters to reflect the options installed in the system. 4. You may return to the Main Menu anytime by press <ESC> . 5. - Page 25 A short description of screen options follows: Date (mm:dd:yy) Set the current date and time. Time (hh:mm:ss) This field records the specifications Primary (Secondary) for all non-SCSI hard disk drives Master/Slave installed in your system. Refer to the respective documentation on how to install the drivers.
-
Page 26: Bios Features Setup
BIOS Features Setup BIOS Features Setup allows you to improve your system performance or set up some system features according to your preference. Run the BIOS Features Setup as follows: 1. Choose ÒBIOS FEATURES SETUPÓ from the Main Menu and a screen with a list of options appears. ROM PCI/ISA BIOS BIOS FEATURES SETUP AWARD SOFTWARE, INC. - Page 27 A short description of screen options follows: Virus Warning Enabled: Activates automatically when the system boots up causing a warning message to appear if there is anything attempts to access the boot sector or hard disk partition table. Disabled: No warning message will appear when there is something attempts to access the boot sector or...
- Page 28 Boot Sequence Default is ÒA, C, SCSIÓ. This option determines which drive to look for first for an operating system. Swap Floppy Drive Choose Enabled or Disabled (default). This option swaps floppy drive assignments when it is enabled. Boot Up Floppy Enabled (default): During POST, Seek BIOS checks the track number of the...
-
Page 29: Chipset Features Setup
PCI/VGA palette Choose Enabled or Disabled (default). It determines whether the Snoop MPEG ISA cards can work with PCI/VGA or not. Video BIOS Enabled (default): Map the VGA Shadow BIOS to system RAM. Disabled: DonÕt map the VGA BIOS to system RAM. C8000-CBFFF to These options are used to shadow DC000-DFFF... - Page 30 ROM PCI/ISA BIOS CHIPSET FEATURES SETUP AWARD SOFTWARE, INC. Bank 0/1 DRAM Timing : FP/EDO 70ns Bank 2/3 DRAM Timing : FP/EDO 70ns Bank 4/5 DRAM Timing : FP/EDO 70ns SDRAM Cycle Length DRAM Read Pipeline : Enabled Cache Rd+CPU Wt Pipeline : Enabled Cache Timing : Fast...
- Page 31 AGP Aperture Size Choose 4 , 8, 16, 32, 64 (default), 128, or 256 MB. Memory mapped and (MB) graphics data structures can reside in a Graphics Aperture. This area is like a linear buffer. BIOS will auto report the starting address of this buffer to the O.S.
-
Page 32: Power Management Setup
Power Management Setup Power Management Setup sets the systemÕs power saving functions. 1. Choose ÒPOWER MANAGEMENT SETUPÓ from the Main Menu and a screen with a list of options appears. ROM PCI/ISA BIOS POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. Primary INTR : ON Power Management : User Define... - Page 33 Video Off Method Choose Blank , DPMS, or V/H Sync+Blank (default). You can chose either DPMS or V/H Sync+Blank when the monitor has the Green function. You need to choose Blank when the monitor does not have the Green function. Note: Some VGA cards don’t allow V/H Sync to be turned...
-
Page 34: Pnp/Pci Configuration Setup
LPT & COM Use the default setting. HDD & FDD Use the default setting. DMA/Master Use the default setting. Modem Ring Enabled: Wake up the system Resume from ring signal. Disabled: (default) Ring signal can not wake up the system. RTC Alarm Enabled: Wake up the system at Resume... - Page 35 ROM PCI/ISA BIOS PNP/PCI CONFIGURATION AWARD SOFTWARE, INC. PNP OS Installed : No CPU to PCI Write Buffer : Enabled Resources Controlled By : Manual PCI Dynamic Bursting : Enabled Reset Configuration Data : Disabled PCI Master 0 WS Write : Enabled ACPI I/O Device Node : Enabled...
- Page 36 Reset Choose Enabled or Disabled (default). Disabled means to retain Configuration Data PnP configuration data in BIOS and Enabled means to reset PnP configuration data in BIOS. ACPI I/O Device Choose Disabled (default) or Node Enabled. Enabled is only used when the ACPI device is installed on to the system.
-
Page 37: Load Setup Defaults
Load Setup Defaults Load Setup Defaults option loads the default system values to the system configuration fields. If the CMOS is corrupted the defaults are loaded automatically. Choose this option and the following message appears: “Load Setup Defaults (Y/N)? N” To use the Setup defaults, change the prompt to ÒYÓ... -
Page 38: Integrated Peripherals
Integrated Peripherals Integrated Peripherals option changes the values of the chipset registers. These registers control system options in the computer. 1. Choose ÒINTEGRATED PERIPHERALSÓ from the Main Menu and a screen with a list of options appears. ROM PCI/ISA BIOS INTEGRATED PERIPHERALS AWARD SOFTWARE, INC. - Page 39 IDE HDD Block Choose Enabled (default) or Disabled. If your hard disk size is Mode larger than 540MB, choose Enabled, and, if you are using the IDE HDD Auto Detection option, the BIOS will choose this option automatically. (Note: Some old HDD models donÕt provide this feature.) IDE Primary...
- Page 40 UART2 Mode Choose Standard (default), HPSIR, or ASKIR. IR Function Choose Half (default), or Full. Duplex Half: DoesnÕt transmit and receive activities at the same time. Full: Transmit and receive activities at the same time. RxD, TxD Active Choose Hi/Hi, Hi/Lo, Lo/Hi, or Lo/Lo (default).
-
Page 41: Supervisor/User Password
Parallel Port EPP Choose EPP1.7 (default) or EPP1.9. EPP1.9 supports hardware Type handshake. This setting is dependent on your EPP device. Note: The above 2 options will not be displayed unless the EPP/ECP function is selected. 3. Press <ESC> and follow the screen instructions to save or disregard your settings. -
Page 42: Ide Hdd Auto Detection
7. Move the cursor to Save & Exit Setup to save the option you did, otherwise the old password will still be there when you turn on your machine next time. 8. Press <ESC> to exit to the Main Menu. Note: If you forget or lose the password, the only way to access the system is to clear the CMOS RAM by... -
Page 43: Exit Without Saving
Exit Without Saving Exit Without Saving allows you to exit the Setup utility without saving the modifications that you have specified. Highlight this option on the Main Menu and the following message appears: Quit Without Saving (Y/N)? N You may change the prompt to ÒYÓ and press <Enter> key to leave this option.
