Intel Pentium Mmxð166/200/233 - SOLTEK SL-53D2 User's Manual & Technical Reference

Intel Pentium MMX–166/200/233
Intel MMX
CPUs
JP2
1 2 JP2
1 2
5 6
11 12
(2.8V)
MMX – 166 MMX – 200
JBF3 JBF3
JBF2 JBF2
JBF1 JBF1
2.5x clock 3.0x clock
Figure 2Ð1. CPU Type Configuration
6
1
JBF3
JBF2
JBF1
MMX – 233
JBF3
JBF2
JBF1
3.5x clock
