Appendix
Eingang Geschwindigkeit (Pin 5)
Properties
Reverse ppolarity protection
Max. voltage
Total control range
Control range conveying operation
EC300 7,85:1
Control range conveying operation
EC300 13:1
Stop-Range
Resolution A/D conversion
Input resistance
Time constants
36 von 38
not galvanically separated
yes
30 V DC
0 to 10 V DC
2,0 to 8,6 V DC
2,0 to 6,0 V DC
0 to 2,0 V DC
8 bit
66 kΩ
4,5 to 5,0 ms
max -30 V DC
for max. 5s
2,0 V = 0,0 m/s
8,6 V = 2,0 m/s
2,0 V = 0,0 m/s
6,0 V = 1,21 m/s
RollerDrive does not rotate
