DIP-Schalter

The DIP switches are used to select the gear ratio of the previously used RollerDrive EC300 and RollerDrive EC310 to
be used in the future. Based on these values, the AdControl determines the necessary change that has to be made to
the speed signal.
In its as-delivered state, the gear ratio EC300 13:1 and EC310 16:1 are set.
DIP switches
7,85:1 / 13:1
Bit 0, Bit 1, Bit 2, Bit 3
Reserve
Gear ratio
RollerDrive EC310
9:1
12:1
16:1
20:1
24:1
36:1
48:1
64:1
96:1
If a different DIP switch combination is set than the one listed in the table, the RollerDrive speed of rotation
will be set to 0 RPM.
