Single-leg/double-leg base units

Advertisement

®
HEALTH
15.
For each foot, a foot cover needs to be installed.
Install RH foot cover so it encompasses leg column, as
shown (15a). Install LH foot cover next to RH foot cover
by sliding downward and engaging RH foot cover (15b)
until it is fully secured into place (15c).
LEG
COLUMN
RH FOOT
COVER
LH FOOT
COVER
RH FOOT
COVER
15a
15b
15c
Page 6 of 7
939549945 Rev E
