3. Place the faucet on the countertop.
4. If the countertop is thin or the faucet is being mounted on the sink itself, place the countertop extender (#11)
from underneath the countertop and tighten it onto the tailpiece (#5). **OPTIONAL**
5. Place the metal washer (#6) onto the tailpiece (#5) from underneath
the countertop.
6. Place the fixing set (#7) onto tailpiece (#5) underneath the countertop and tighten it.
7. Connect pullout hose (#10) to copper tube. see details on page 2
8. Place the weight (#8) onto pullout hose (#10).
9. Screw in the hot and cold waterlines (#9) and attach them to the water supply.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Kraus KPF-1621
Summary of Contents for Kraus KPF-1621
- Page 1 3. Place the faucet on the countertop. 4. If the countertop is thin or the faucet is being mounted on the sink itself, place the countertop extender (#11) from underneath the countertop and tighten it onto the tailpiece (#5). **OPTIONAL** 5.
- Page 2 Rubber Washe Tailpiece Metal Washer Fixing set Weight Hot & Cold Water Lines Pullout hose (ALREADY ATTACHED) Faucet Extender (optional) IMPORTANT Screw at back of faucet tightens the goose neck to the body. Connecting pullout hose to copper tube Copper Tube...
