Kraus KHF200-30 Installation Manual
Farmhouse stainless steel sink
Hide thumbs
Also See for KHF200-30:
- Installation manual (12 pages) ,
- Installation manual (17 pages) ,
- Installation manual (31 pages)
Related Manuals for Kraus KHF200-30
Summary of Contents for Kraus KHF200-30
- Page 1 I N S TA L L AT I O N MA N UA L Farmhouse Stainless Steel Sink KHF200-30 / KHF200-33 / KHF200-36 KHF203-33 / KHF203-36 KHF204-33 www.kraususa.com I toll free: 1.800.775.0703 I © 2016 Kraus USA Inc.
-
Page 2: Khf204
Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help. - Page 3 Toll-Free: 800-775-0703 or Customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional.
-
Page 4: Parts List
Acetone Phillips Screwdriver Tape Measure Pencil Screwdriver NOTE: Specialized tools may be necessary to install Kraus Stainless Steel Undermount sinks with countertop materials other than wood, marble, or granite Parts List • Cut-Out Template • Bottom Grids • 1 Drain - BST-1 for Single Bowl... - Page 5 Dimensions KHF200-30 KHF200-36 KHF200-30 KHF200-33 27” 30” 33” 686mm 27” 762mm 838mm 686mm 29-3/4” 32-7/8” 35-7/8” 756mm 29-3/4” 835mm 911mm 756mm KHF200-30 KHF200-33 KHF200-36 29 3/4” x 20 3/4” x 10” 32 7/8” x 20 3/4” x 10” 35 7/8” x 20 3/4” x 10”...
-
Page 6: Khf203
1. Measure & Build Supports • Measure the actual height of apron • Build supports on inside of cabinet based on sink measurements Installer Tip: Support Options • 1 ¼” Angle Irons • (2) 2”x 4’ • 3/4” Plywood SUPPORTS... -
Page 7: Khf203
2. Cut Cabinet Front • Measure height of apron front. Add 1/16” to the dimension when you mark base cabinet front cutout. Use jigsaw to cut... - Page 8 3. Install Sink • Place sink in opening. The weight of sink should be sustained by the built supports • Make sure sink is leveled from front to back and side to side • Uses silicone to fill in gaps where necessary...
- Page 9 4. Cut Countertop • Use a bead of silicone (or preferred adhesive) around the rim of the sink. Check the alignment of the sink to the cutout in the countertop. Place countertop cutout hole over sink and press firmly Installer Tip: Use acetone or rubbing alcohol to remove any excess sealant...
- Page 10 5. Installing Plumbing Fixtures • Connect drain, trap to drain and water supply connections to the faucet according to manufacturer’s instruction. • Run water into sink and check for leaks...
- Page 11 Our customer service hours are Monday – Friday, 9am – 8pm EST. Be sure to visit our website at www.kraususa.com If you are a HOMEOWNER please contact a Kraus Customer Service Representative at: Kraus USA, Inc. 12 Harbor Park Drive...
- Page 12 Please take a moment to share your experience. Visit http://www.kraususa.com/review to let us know what you think about your new Kraus product. Contact Us to Learn More 1.800.775.0703 / www.kraususa.com / customerservice@kraususa.com Like & Follow KrausUSA Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance www.kraususa.com...
- Page 13 I N S TA L L AT I O N MA N UA L Crespo™ Single Lever Pull Down Kitchen Faucet KPF-2720 www.kraususa.com I toll free: 1.800.775.0703 I © 2014-2015 Kraus USA Inc. I REV. March 30, 2017...
- Page 14 Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help.
- Page 15 8 5/16” • Make sure you have all necessary parts by checking the diagram and parts list. (257mm) (21mm) If any part is missing or damaged, please contact Kraus Customer Service at 1 15/16” ∅ 800-775-0703 for a replacement 50mm) 1 3/8”...
- Page 16 Diagram and Parts List A. Spray Head B. Faucet Body C. Deck & Putty Plate D. Base E. Spray Hose F. Supply Hose G. Hot & Cold Waterlines H. Weight I. Quick Connect J. Hex Wrench Set J1. 2.5mm J2. 4mm...
- Page 17 Faucet Dimensions 10-1/8” 10-1/8” (257mm) (258mm) 8-3/8” 4-3/8” (213.5mm) (110mm) º 2-1/2” (63mm) Check Value 9/16-24 UNEF (3/8” Compression)
- Page 18 Step 1A: Install base without deck & putty plate Insert base (D) into sink or countertop with “FR↑NT” facing forward. Tighten screws on base (D) with 4mm hex wrench (J) until base is secure on sink or countertop Installer Tip: Rotate the two half-moon shaped locking nuts inward before inserting base (D) into sink or...
- Page 19 Step 1B: Install base with deck & putty plate Place a bead of clear silicone sealant (not included) around the edge of the putty plate (C). Secure deck & putty plate (C) on sink or countertop. Insert base (D) into hole of deck &...
- Page 20 Step 2: Install faucet Remove Quick Connect (I) from spray hose (E). Insert spray hose (E) into small hole of base (D). Insert hot & cold waterlines (G) and supply hose (F), one by one, in large hole of base Step 3: Secure faucet Align arrow on faucet body (B) with arrow on base (D).
- Page 21 Step 4: Connect waterlines to main valve Thread hot & cold waterlines (G) onto angle stops. Tighten with adjustable wrench until snug. Turn on the angle stops and check for leaks (DO NOT TURN FAUCET ON) Installer Tip: Use two wrenches when securing waterlines to angle stops to Cold...
- Page 22 Step 6: Install weight Attach weight (H) on the Cold designated mark on the spray hose (E) Cold Designated Mark Step 7: Flush faucet Remove spray head (A). Hold tip of spray hose (E). Turn faucet on for 1 minute to flush any debris. Reconnect spray head (A)
- Page 23 Replacement Part List 1. A Index Button B Set Screw 2. Metal Handle 3. Cartridge Cover 4. Locking Nut 5. Cartridge 6. Plastic Cover 7. Spray Head 8. Set Screw 9. Cover & Putty Plate 10. Quick Connect Assembly 11. Spray Hose 12.
- Page 24 Trouble - Shooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: P R O B L E M C A U S E A C T I O N Leaking from spray Quick Connect (10) may Remove Quick Connect...
- Page 25 Do not clean with soaps, acid, polish, abrasives, or harsh cleaners Do not use cloth with a coarse surface Left Unscrew the aerator and clean when necessary Open Hot Water *This installation manual is subject to change without further notice. Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance...
- Page 26 Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 Toll-free 800-775-0703 Customerservice@kraususa.com If you are a plumbing contractor or trade professional please contact a Kraus Pro Representative at: Kraus USA, Inc. 12 Harbor Park Drive Port Washington, NY 11050 516-801-8955 Proservice@kraususa.com...
- Page 27 www.kraususa.com...
- Page 28 Please take a moment to share your experience. Visit http://www.kraususa.com/review to let us know what you think about your new Kraus product. Contact Us to Learn More 1.800.775.0703 / www.kraususa.com / customerservice@kraususa.com Like & Follow KrausUSA Download the Kraus Care & Maintenance Guide at: http://www.kraususa.com/maintenance www.kraususa.com...
- Page 29 I N S TA L L AT I O N MA N UA L Soap Dispensers KSD-30 KSD-33 KSD-35 KSD-41 KSD-42 SD-20 SD-25 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2014-2015 Kraus USA Inc. I REV. August 16, 2016...
- Page 30 Thank you for your purchase We would like to take this opportunity to thank you for choosing Kraus. We hope that you are completely satisfied with your purchase, and enjoy it for years to come. If you have any questions, or require technical assistance, please contact us at 800.775.0703 and one of our representatives will be happy to help.
- Page 31 Toll-Free: 800.775.0703 or Customerservice@kraususa.com The step-by-step guidelines in the installation instructions are a general reference for installing a Kraus Sink. Should there be any discrepancies, Kraus cannot be held liable. It is recommended to install all Kraus products by hiring a licensed professional.
- Page 32 GDA-1 Diagram and Parts List: a. Pump b. Dispenser Base c. Rubber Washer A d. Rubber Washer B e. Mounting Nut f. Dispenser Bottle TOOLS REQUIRED: *Adjustable Wrench...
- Page 33 Step 1 Disassemble soap dispenser...
- Page 34 Step 2 Install dispenser base (b) with rubber washer A (c) attached into the hole in the countertop. Re-install rubber washer B (d) and mounting nut (e) on the dispenser base (b) from underneath the countertop. Tighten mounting nut (e) with adjustable wrench until snug...
- Page 35 Step 3 Screw the dispenser bottle (f ) to the dispenser base (b) from underneath the countertop. Tighten as required. Fill the dispenser bottle (f ) from the top with 12 ounces of soap...
- Page 36 Step 4 Insert pump (a) into dispenser base (b) from the top. Press the pump several times to make sure soap is evenly distributed Press...
