  • Page 1 GASFORNUIS MET ELEKTRISCHE OVEN KUCHNIA GAZOWA Z PIEKARNIKIEM ELEKTRYCZNYM 2952271 / FAE92M00 2952481 / FAE93M00 I N S T A L L A T I O N S - , B E D I E N U N G S -...
  • Page 2 TECHNISCHE ÄNDERUNGEN VORBEHALTEN! TECHNICAL CHANGES RESERVED! SOUS RÉSERVE DE MODIFICATIONS TECHNIQUES ! CI RISERVIAMO LA POSSIBILITÀ DI INTRODURRE MODIFICHE TECNICHE! ¡SE RESERVA EL DERECHO A INTRODUCIR MODIFICACIONES TÉCNICAS! SUJEITO A ALTERAÇÕES TÉCNICAS! TECHNISCHE WIJZIGINGEN VOORBEHOUDEN! WPROWADZANIE ZMIAN TECHNICZNYCH ZASTRZEŻONE!
  • Page 3: Table Of Contents

    Replacement of nozzle and adjustment of gas burner primary air supply ......15 9.3. Replacement of gas burner ignition flame nozzle ..............15 10. APPLIANCE DISPOSAL ........................16 ATTACHMENTS ............................I Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany...
  • Page 4: Index

    ENGLISH INDEX Adjustment of gas burner primary air supply 15 Oven - safety thermostat 5 APPLIANCE DISPOSAL 16 Oven switching on and off 7 Check-up 14 Packaging 11 Cleaning of the heating plate 9 Proper maintenance 8 Cleaning of the oven 9 Protection appliances 5 Connection to the mains 13 Rating plate 5...
  • Page 5: Safety

    ENGLISH SAFETY To provide hygiene and protect foods from dirt, all Read carefully the guidelines and the elements that have direct or indirect contact with the foods and all border areas must be instructions in the instruction manual thoroughly cleaned. Use only the cleaning agents before you use the appliance.
  • Page 6: General Information And Warnings

    ENGLISH GENERAL INFORMATION AND WARNINGS 4.1. General guidelines The manual has been edited by the manufacturer Special symbols, described below, have been to provide the authorized personnel with the used to stress important information or draw information necessary to work with the appliance. attention to essential data: We recommend the intended readers to read the Caution - warning...
  • Page 7: Protection Appliances

    ENGLISH 4.3. Protection appliances The device is equipped with the following 3. Oven - safety thermostat: it blocks the electric protection systems. The drawing presents layout power supply in the case of overheating. of the devices. 1. Gas valve: for opening and closing the gas Check every day that the supply line.
  • Page 8: Replacement Of Components (Service Technician)

    ENGLISH 4.5. Replacement of components (service technician) If necessary, exchange the used components to Before exchange of the the original spare parts. component switch on all the existing We are not liable for personal injury or protection appliances. First of all, damage to the components that arise due to switch off the gas valve and prevent application of other spare parts than original...
  • Page 9: Ignition Of Gas Burners

    ENGLISH 5.2. Ignition of gas burners IGNITION A) Press the control knob of selected burner and C) To ignite the burner rotate the control knob anti- rotate anti-clockwise to ignite the ignition flame clockwise (position 2). (position 1). Ignite the ignition flame with use D) Set the gas burner power (position 3).
  • Page 10: Guidelines On How To Use The Device

    ENGLISH 5.4. Guidelines on how to use the device When the device will not be used for a longer In order to brown the product surface time, follow the instructions below: put in on the upper grill and switch the upper 1.
  • Page 11: Cleaning Of The Heating Plate

    ENGLISH 6.3. Cleaning of the heating plate Follow the instructions below. ID 06 Remove the gas burners grates (A). Remove the flame distributor B. Thoroughly clean the burner body (C) and flame distributor (B). Thoroughly clean the recess D with use of soft cloth and neutral cleaning agent.
  • Page 12: Troubleshooting

    ENGLISH TROUBLESHOOTING The information below is provided to recognize Some of the failures can be repaired by the user, and repair any failures that may occur when others require thorough specialist knowledge. operating the appliance. Such problems may be solved exclusively by the qualified personnel.
  • Page 13: Installation

    ENGLISH INSTALLATION 8.1. Packaging and unpacking During unloading when installing When collecting the goods check if the packaging appliance follow information from is complete and has not been damaged during manufacturer placed directly on the packaging transport. and in this manual. Any damage should be immediately reported to the shipping company.
  • Page 14: Extraction Of Fumes

    ENGLISH Internal installation of the gas supply and the rooms in which the device is housed must comply with the When the device is to be local regulations applicable in the country in which installed near the walls, partitions, the device is used (Regulation of 12th of July 1996 kitchen cabinets, decorative elements, and UNI-CIG 87/23).
  • Page 15: Connection To The Mains (Service Technician)

    ENGLISH If there are significant pressure differences in the gas supply installation, it is recommended to install a pressure regulator. After the installation, check the gas connection for tightness. When looking for gas leaks do not use the open flame! ID 12 8.6.
  • Page 16: Inspection (Service Technician)

    ENGLISH 8.8. Inspection (service technician) Before starting the device the installation check- 4. Check if the safety thermostat operates up should be run to evaluate the working properly. conditions of every single component and 5. Check gas lines for gas leaks. recognize any errors.
  • Page 17: Replacement Of Nozzle And Adjustment Of Gas Burner Primary Air Supply

    ENGLISH 9.2. Replacement of nozzle and adjustment of gas burner primary air supply Follow the instructions below. Loosen the screw E and set the Venturi pipe (F). Close the gas cut-off valve. When required, replace the nozzle (G) with a Remove the gas burners grates (A).
  • Page 18: Appliance Disposal

    Bartscher GmbH Franz-Kleine-Str. 28 D-33154 Salzkotten phone: +49 (0) 5258 971-0 Germany fax: +49 (0) 5258 971-120...
  • Page 19: Attachments

    ANLAGEN ATTACHMENTS ANNEXES ALLEGATI ANEXOS ANEXOS BIJLAGEN ZAŁĄCZNIKI...
  • Page 20 Brander Gasverbruik Model Palnik Zużycie gazu Ø 75 Ø 105 Ø 130 3,5 kW 5 kW 8 kW m³/h m³/h kg/h kg/h FAE92M00 24,5 2,59 3,02 1,93 1,90 FAE93M00 37,5 3,97 4,62 2,96 2,91 Modelle Backofen Leistung Daten zu Elektrik...
  • Page 21 ANSCHLUSSSCHEMA - CONNECTION CARD - FICHE DES RACCORDEMENTS - FAE92M00 SCHEDA ALLACCIAMENTI - FICHA DE ENLACES - ESQUEMA DAS CONEXÕES - PLAN AANSLUITINGEN - SCHEMAT PODŁĄCZENIA " ø75 3.5kW ø105 5kW ø130 8kW...
  • Page 22 ANSCHLUSSSCHEMA - CONNECTION CARD - FICHE DES RACCORDEMENTS - FAE93M00 SCHEDA ALLACCIAMENTI - FICHA DE ENLACES - ESQUEMA DAS CONEXÕES - PLAN AANSLUITINGEN - SCHEMAT PODŁĄCZENIA 1200 " ø75 3.5kW ø75 3.5kW ø105 5kW ø105 5kW ø130 8kW ø130 8kW...
  • Page 23 Tabelle: Düsen für Brenner - Table: Burner nozzles - Tableau : Buses du brûleur - Tabella: ugelli dei bruciatori 3,5 kW - Tabla: Toberas del quemador – Tabela: Bicos para queimadores - Tabel: mondstukken voor de brander - Tabela: Dysze palnika H mm Qn max Qn min...
  • Page 24 Tabelle: Düsen für Brenner - Table: Burner nozzles - Tableau : Buses du brûleur - Tabella: ugelli dei bruciatori 3,5 kW - Tabla: Toberas del quemador – Tabela: Bicos para queimadores - Tabel: mondstukken voor de brander - Tabela: Dysze palnika H mm Qn max Qn min...
  • Page 25 Tabelle: Düsen für Brenner - Table: Burner nozzles - Tableau : Buses du brûleur - Tabella: ugelli dei bruciatori 5 kW - Tabla: Toberas del quemador – Tabela: Bicos para queimadores - Tabel: mondstukken voor de brander - Tabela: Dysze palnika H mm Qn max Qn min...
  • Page 26 Tabelle: Düsen für Brenner - Table: Burner nozzles - Tableau : Buses du brûleur - Tabella: ugelli dei bruciatori 5 kW - Tabla: Toberas del quemador – Tabela: Bicos para queimadores - Tabel: mondstukken voor de brander - Tabela: Dysze palnika H mm Qn max Qn min...
  • Page 27 Tabelle: Düsen für Brenner - Table: Burner nozzles - Tableau : Buses du brûleur - Tabella: ugelli dei bruciatori 8 kW - Tabla: Toberas del quemador – Tabela: Bicos para queimadores - Tabel: mondstukken voor de brander - Tabela: Dysze palnika H mm Qn max Qn min...
  • Page 28 Tabelle: Düsen für Brenner - Table: Burner nozzles - Tableau : Buses du brûleur - Tabella: ugelli dei bruciatori 8 kW - Tabla: Toberas del quemador – Tabela: Bicos para queimadores - Tabel: mondstukken voor de brander - Tabela: Dysze palnika H mm Qn max Qn min...
  • Page 29 Tabelle der Gas-Eigenschaften - Table of gas characteristics - Tableau des propriétés du gaz - Tabella: caratteristiche di gas - Tabla de propiedades del gas - Tabela de propriedades de gás - Tabel van gaseigenschappen - Tabela własności gazu Familie Gastypen Wobbeindex Unterer Heizwert...
  • Page 30 FAE92M00 SCHALTPLAN - ELECTRIC DIAGRAM – SCHÉMA ÈLECTRIQUE - SCHEMA ELETTRICO - ESQUEMA ELÉCTRICO - ESQUEMA ELÉCTRICO – FAE93M00 ELEKTRISCH SCHEMA - SCHEMAT IDEOWY 111 61134 Rev. 02...
  • Page 31 NOTE XIII...
  • Page 32 LAUT GESETZLICHER VORSCHRIFT STEHT DIESES HANDBUCH UNTER EIGENTUMS- VORBEHALT UND DARF AUS DIESEM GRUND NICHT OHNE UNSERE GENEHMIGUNG VERVIELFÄLTIGT UND/ODER IN JEGLICHER FORM AN DRITTE WEITERGEGEBEN WERDEN! IN COMPLIANCE WITH THE LAW IN FORCE,IT IS PROHIBITED TO REPRODUCE AND/OR DISTRIBUTE THIS MANUAL IN ANY WAY WITHOUT THE AUTHORISATION OF THE PROPRIETOR! AUX TERMES DE LA LOI, LA PROPRIETE DE CETTE NOTICE EST RESERVEE.
